Name: Inter-Tech BPS-850 power supply unit 850 W 20+4 pin ATX ATX Black
Brand: Inter-Tech
SKU: 88882242
Price: 92.45 GBP
Availability: OutOfStock

Inter-Tech Coba CES-350B power supply unit 350 W 20+4 pin ATX ATX Silver

£62.40

RRP £84.77

Save £32.76

In stock

More Info

Add to Wish List Add to Compare

Inter-Tech GF-350 BULK power supply unit 350 W 20+4 pin ATX Flex ATX Silver

£88.54

RRP £106.24

Save £32.46

Out of stock

Add to Wish List Add to Compare

More Info

Add to Wish List Add to Compare

Inter-Tech SAMA XPH-850A power supply unit 850 W 20+4 pin ATX ATX Black

£165.89

RRP £228.10

Save £89.86

Out of stock

Add to Wish List Add to Compare

More Info

Add to Wish List Add to Compare

Inter-Tech SAMA XPH-1200A power supply unit 1200 W 20+4 pin ATX ATX Black

£180.14

RRP £267.21

Save £117.09

Out of stock

Add to Wish List Add to Compare

More Info

Add to Wish List Add to Compare

Inter-Tech SAMA XPH-1000A power supply unit 1000 W 20+4 pin ATX ATX Black

£174.96

RRP £242.03

Save £96.23

Out of stock

Add to Wish List Add to Compare

More Info

Add to Wish List Add to Compare

Inter-Tech BPS-850 power supply unit 850 W 20+4 pin ATX ATX Black

£92.45

RRP £129.42

Save £52.38

Out of stock

Add to Wish List Add to Compare

More Info

Add to Wish List Add to Compare

Cooling
Fan diameter	12 cm
Number of fans	1 fan(s)
Fan location	Side
Cooling type	Active
Performance
On/off switch	Yes
Power supply unit (PSU) form factor	ATX
80 PLUS certification	80 PLUS Bronze
Purpose	PC
ATX version	2.3
Noise level	25 dB
Harmonized System (HS) code	84733020
Design
80 PLUS certification	80 PLUS Bronze
Product colour	Silver
Fan diameter	12 cm
On/off switch	Yes
Number of fans	1 fan(s)
Fan location	Side
Cooling type	Active
Power
Total power	350 W
AC input voltage	115 - 230 V
AC input frequency	50 - 60 Hz
Input current	8 A
Power Factor Correction (PFC) type	Active
Maximum input current (@110V)	+3.3V,+5Vsb,+12V1,-12V,+12V2,+5V
Combined power (+3.3V)	103 W
Combined power (+5V)	103 W
Max output current (+3.3V)	15 A
Max output current (+12V1)	15 A
Max output current (+12V2)	15 A
Max output current (+5V)	12 A
Max output current (-12V)	0.3 A
Max output current (+5Vsb)	2.5 A
Power protection features	Over voltage, Over current, Short circuit
Ports & interfaces
Motherboard power connector	20+4 pin ATX
Number of SATA power connectors	3
Peripheral (Molex) power connectors (4-pin)	2
PCI Express power connectors (6+2 pin)	1
CPU power connector (4+4 pin)	Yes
ATX power connector (20+4 pin)	Yes
Weight & dimensions
Width	150 mm
Depth	140 mm
Height	86 mm
Technical details
Compliance certificates	RoHS
Certificates
80 PLUS certification	80 PLUS Bronze
Logistics data
Harmonized System (HS) code	84733020
Other features
Harmonized System (HS) code	84733020

Cooling
Fan diameter	12 cm
Number of fans	1 fan(s)
Fan location	Side
Cooling type	Active
Performance
On/off switch	Yes
Power supply unit (PSU) form factor	ATX
80 PLUS certification	80 PLUS Bronze
Purpose	PC
ATX version	2.3
Noise level	25 dB
Harmonized System (HS) code	84733020
Design
80 PLUS certification	80 PLUS Bronze
Product colour	Silver
Fan diameter	12 cm
On/off switch	Yes
Number of fans	1 fan(s)
Fan location	Side
Cooling type	Active
Power
Total power	350 W
AC input voltage	115 - 230 V
AC input frequency	50 - 60 Hz
Input current	8 A
Power Factor Correction (PFC) type	Active
Maximum input current (@110V)	+3.3V,+5Vsb,+12V1,-12V,+12V2,+5V
Combined power (+3.3V)	103 W
Combined power (+5V)	103 W
Max output current (+3.3V)	15 A
Max output current (+12V1)	15 A
Max output current (+12V2)	15 A
Max output current (+5V)	12 A
Max output current (-12V)	0.3 A
Max output current (+5Vsb)	2.5 A
Power protection features	Over voltage, Over current, Short circuit
Ports & interfaces
Motherboard power connector	20+4 pin ATX
Number of SATA power connectors	3
Peripheral (Molex) power connectors (4-pin)	2
PCI Express power connectors (6+2 pin)	1
CPU power connector (4+4 pin)	Yes
ATX power connector (20+4 pin)	Yes
Weight & dimensions
Width	150 mm
Depth	140 mm
Height	86 mm
Technical details
Compliance certificates	RoHS
Certificates
80 PLUS certification	80 PLUS Bronze
Logistics data
Harmonized System (HS) code	84733020
Other features
Harmonized System (HS) code	84733020

Cooling
Number of fans	1 fan(s)
Cooling type	Active
Design
80 PLUS certification	80 PLUS Gold
Product colour	Silver
Number of fans	1 fan(s)
Cooling type	Active
Power
Total power	350 W
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Input current	8 A
Power Factor Correction (PFC) type	Active
Combined power (+3.3V)	60 W
Combined power (+12V)	348 W
Combined power (+5V)	60 W
Combined power (-12V)	3.6 W
Combined power (+5Vsb)	12.5 W
Max output current (+3.3V)	10 A
Max output current (+12V)	29 A
Max output current (+5V)	10 A
Max output current (-12V)	0.3 A
Max output current (+5Vsb)	2.5 A
Power protection features	Over current, Over voltage, Short circuit, Under voltage
Efficiency	91.9%
Ports & interfaces
Motherboard power connector	20+4 pin ATX
Number of SATA power connectors	3
Peripheral (Molex) power connectors (4-pin)	3
ATX power connector (20+4 pin)	Yes
EPS power connector (4+4 pin)	Yes
Performance
Power supply unit (PSU) form factor	Flex ATX
80 PLUS certification	80 PLUS Gold
Purpose	Server
Mean time between failures (MTBF)	50000 h
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 80 °C
Operating relative humidity (H-H)	20 - 80%
Storage relative humidity (H-H)	10 - 50%
Weight & dimensions
Width	150 mm
Depth	81.5 mm
Height	40.5 mm
Weight	850 g
Packaging data
Package weight	910 g
Certificates
80 PLUS certification	80 PLUS Gold

Cooling
Number of fans	1 fan(s)
Cooling type	Active
Design
80 PLUS certification	80 PLUS Gold
Product colour	Silver
Number of fans	1 fan(s)
Cooling type	Active
Power
Total power	350 W
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Input current	8 A
Power Factor Correction (PFC) type	Active
Combined power (+3.3V)	60 W
Combined power (+12V)	348 W
Combined power (+5V)	60 W
Combined power (-12V)	3.6 W
Combined power (+5Vsb)	12.5 W
Max output current (+3.3V)	10 A
Max output current (+12V)	29 A
Max output current (+5V)	10 A
Max output current (-12V)	0.3 A
Max output current (+5Vsb)	2.5 A
Power protection features	Over current, Over voltage, Short circuit, Under voltage
Efficiency	91.9%
Ports & interfaces
Motherboard power connector	20+4 pin ATX
Number of SATA power connectors	3
Peripheral (Molex) power connectors (4-pin)	3
ATX power connector (20+4 pin)	Yes
EPS power connector (4+4 pin)	Yes
Performance
Power supply unit (PSU) form factor	Flex ATX
80 PLUS certification	80 PLUS Gold
Purpose	Server
Mean time between failures (MTBF)	50000 h
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-20 - 80 °C
Operating relative humidity (H-H)	20 - 80%
Storage relative humidity (H-H)	10 - 50%
Weight & dimensions
Width	150 mm
Depth	81.5 mm
Height	40.5 mm
Weight	850 g
Packaging data
Package weight	910 g
Certificates
80 PLUS certification	80 PLUS Gold

Cooling
Number of fans	1 fan(s)
Fan location	Top
Cooling type	Active
Performance
On/off switch	Yes
Power supply unit (PSU) form factor	ATX
80 PLUS certification	80 PLUS Platinum
Purpose	PC
ATX version	3.0
Design
80 PLUS certification	80 PLUS Platinum
Product colour	Black
On/off switch	Yes
Number of fans	1 fan(s)
Fan location	Top
Cooling type	Active
Power
Total power	850 W
AC input voltage	100 - 240 V
AC input frequency	50/60 Hz
Input current	8/10 A
Power Factor Correction (PFC) type	Active
Combined power (+3.3V)	100 W
Combined power (+12V)	849.6 W
Combined power (+5V)	100 W
Combined power (-12V)	4.8 W
Combined power (+5Vsb)	15 W
Max output current (+3.3V)	20 A
Max output current (+12V)	70.8 A
Max output current (+5V)	20 A
Max output current (-12V)	0.4 A
Max output current (+5Vsb)	3 A
Power protection features	Over current, Over voltage, Short circuit, Under voltage
Ports & interfaces
Motherboard power connector	20+4 pin ATX
Number of SATA power connectors	8
Peripheral (Molex) power connectors (4-pin)	4
PCI Express power connectors (6+2 pin)	3
ATX power connector (20+4 pin)	Yes
Cabling type	Fully-Modular
EPS power connector (4+4 pin)	Yes
Number of EPS connectors	2
Operational conditions
Operating temperature (T-T)	0 - 40 °C
Storage temperature (T-T)	-40 - 70 °C
Operating relative humidity (H-H)	10 - 90%
Storage relative humidity (H-H)	50 - 95%
Weight & dimensions
Width	150 mm
Depth	155 mm
Height	86 mm
Weight	2.5 kg
Packaging data
Package type	Box
Package weight	2.94 kg
Certificates
80 PLUS certification	80 PLUS Platinum
