Cooling | |
---|---|
Fan diameter | 12 cm |
Number of fans | 1 fan(s) |
Fan location | Top |
Cooling type | Active |
Performance | |
On/off switch | Yes |
Power supply unit (PSU) form factor | ATX |
Noise level (quiet mode, 50%) | 29 dB |
Noise level (silent mode, <30%) | 20 dB |
Noise level (full-load mode, 100%) | 39 dB |
80 PLUS certification | 80 PLUS Bronze |
Purpose | PC |
ATX version | 2.31 |
Noise level | 39 dB |
Mean time between failures (MTBF) | 100000 h |
Certification | CE/CCC/BSMI/KCC/EAC/UL/TUV/RCM/FCC/PSE |
Bearing technology | HDB |
Harmonized System (HS) code | 84733020 |
Design | |
80 PLUS certification | 80 PLUS Bronze |
Certification | CE/CCC/BSMI/KCC/EAC/UL/TUV/RCM/FCC/PSE |
Product colour | Black |
Fan diameter | 12 cm |
On/off switch | Yes |
Number of fans | 1 fan(s) |
Fan location | Top |
Cooling type | Active |
Power | |
Total power | 650 W |
Maximum input current (@220V) | 4 A |
AC input voltage | 100 - 240 V |
Input current | 9 - 4 A |
Power Factor Correction (PFC) type | Active |
Maximum input current (@110V) | 9 A |
Combined power (+3.3V) | 108 W |
Combined power (+12V) | 648 W |
Combined power (+5V) | 108 W |
Combined power (-12V) | 3.6 W |
Combined power (+5Vsb) | 12.5 W |
Max output current (+3.3V) | 18 A |
Max output current (+12V) | 54 A |
Max output current (+5V) | 15 A |
Max output current (-12V) | 0.3 A |
Max output current (+5Vsb) | 2.5 A |
Power protection features | Over power, Overcharge, Short circuit, Under voltage |
Power management | Yes |
Ports & interfaces | |
Motherboard power cable length | 60 cm |
SATA power cable length | 150,500 mm |
Peripheral (Molex) power cable length | 150,500 mm |
PCI Express power cable length | 65 cm |
CPU power cable length | 60 cm |
Motherboard power connector | 20+4 pin ATX |
Number of SATA power connectors | 6 |
Peripheral (Molex) power connectors (4-pin) | 3 |
PCI Express power connectors (6+2 pin) | 4 |
CPU P4 connector (4-pin) | 1 |
CPU power connector (4+4 pin) | Yes |
Floppy disk drive connector | Yes |
ATX power connector (20+4 pin) | Yes |
Cabling type | Non-Modular |
Certificates | |
Certification | CE/CCC/BSMI/KCC/EAC/UL/TUV/RCM/FCC/PSE |
80 PLUS certification | 80 PLUS Bronze |
Weight & dimensions | |
Width | 140 mm |
Depth | 150 mm |
Height | 86 mm |
Packaging data | |
Package type | Box |
Logistics data | |
Harmonized System (HS) code | 84733020 |
Other features | |
Noise level (quiet mode, 50%) | 29 dB |
Noise level (silent mode, <30%) | 20 dB |
Noise level (full-load mode, 100%) | 39 dB |
Power management | Yes |
Harmonized System (HS) code | 84733020 |
Cooling | |
---|---|
Fan diameter | 12 cm |
Number of fans | 1 fan(s) |
Fan location | Top |
Cooling type | Active |
Performance | |
On/off switch | Yes |
Power supply unit (PSU) form factor | ATX |
Noise level (quiet mode, 50%) | 29 dB |
Noise level (silent mode, <30%) | 20 dB |
Noise level (full-load mode, 100%) | 39 dB |
80 PLUS certification | 80 PLUS Bronze |
Purpose | PC |
ATX version | 2.31 |
Noise level | 39 dB |
Mean time between failures (MTBF) | 100000 h |
Certification | CE/CCC/BSMI/KCC/EAC/UL/TUV/RCM/FCC/PSE |
Bearing technology | HDB |
Harmonized System (HS) code | 84733020 |
Design | |
80 PLUS certification | 80 PLUS Bronze |
Certification | CE/CCC/BSMI/KCC/EAC/UL/TUV/RCM/FCC/PSE |
Product colour | Black |
Fan diameter | 12 cm |
On/off switch | Yes |
Number of fans | 1 fan(s) |
Fan location | Top |
Cooling type | Active |
Power | |
Total power | 650 W |
Maximum input current (@220V) | 4 A |
AC input voltage | 100 - 240 V |
Input current | 9 - 4 A |
Power Factor Correction (PFC) type | Active |
Maximum input current (@110V) | 9 A |
Combined power (+3.3V) | 108 W |
Combined power (+12V) | 648 W |
Combined power (+5V) | 108 W |
Combined power (-12V) | 3.6 W |
Combined power (+5Vsb) | 12.5 W |
Max output current (+3.3V) | 18 A |
Max output current (+12V) | 54 A |
Max output current (+5V) | 15 A |
Max output current (-12V) | 0.3 A |
Max output current (+5Vsb) | 2.5 A |
Power protection features | Over power, Overcharge, Short circuit, Under voltage |
Power management | Yes |
Ports & interfaces | |
Motherboard power cable length | 60 cm |
SATA power cable length | 150,500 mm |
Peripheral (Molex) power cable length | 150,500 mm |
PCI Express power cable length | 65 cm |
CPU power cable length | 60 cm |
Motherboard power connector | 20+4 pin ATX |
Number of SATA power connectors | 6 |
Peripheral (Molex) power connectors (4-pin) | 3 |
PCI Express power connectors (6+2 pin) | 4 |
CPU P4 connector (4-pin) | 1 |
CPU power connector (4+4 pin) | Yes |
Floppy disk drive connector | Yes |
ATX power connector (20+4 pin) | Yes |
Cabling type | Non-Modular |
Certificates | |
Certification | CE/CCC/BSMI/KCC/EAC/UL/TUV/RCM/FCC/PSE |
80 PLUS certification | 80 PLUS Bronze |
Weight & dimensions | |
Width | 140 mm |
Depth | 150 mm |
Height | 86 mm |
Packaging data | |
Package type | Box |
Logistics data | |
Harmonized System (HS) code | 84733020 |
Other features | |
Noise level (quiet mode, 50%) | 29 dB |
Noise level (silent mode, <30%) | 20 dB |
Noise level (full-load mode, 100%) | 39 dB |
Power management | Yes |
Harmonized System (HS) code | 84733020 |
Save £36.61
Cooling | |
---|---|
Fan diameter | 12 cm |
Number of fans | 1 fan(s) |
Cooling type | Active |
Performance | |
On/off switch | Yes |
Power supply unit (PSU) form factor | ATX |
80 PLUS certification | 80 PLUS Bronze |
Purpose | PC |
Harmonized System (HS) code | 84733020 |
Design | |
80 PLUS certification | 80 PLUS Bronze |
Product colour | Black |
Fan diameter | 12 cm |
On/off switch | Yes |
Number of fans | 1 fan(s) |
Cooling type | Active |
Power | |
Total power | 550 W |
Maximum input current (@220V) | 4 A |
AC input voltage | 100 - 240 V |
Power Factor Correction (PFC) type | Active |
Maximum input current (@110V) | 8 A |
Combined power (+3.3V) | 110 W |
Combined power (+12V) | 546 W |
Combined power (+5V) | 110 W |
Combined power (-12V) | 3.6 W |
Combined power (+5Vsb) | 12.5 W |
Max output current (+3.3V) | 20 A |
Max output current (+12V) | 45.5 A |
Max output current (+5V) | 20 A |
Max output current (-12V) | 0.3 A |
Max output current (+5Vsb) | 2.5 A |
Power protection features | Over current, Over power, Over voltage, Overheating, Short circuit |
Efficiency | 85% |
Ports & interfaces | |
Motherboard power cable length | 60 cm |
Motherboard power connector | 20+4 pin ATX |
Number of SATA power connectors | 5 |
Peripheral (Molex) power connectors (4-pin) | 2 |
EPS power connector (8-pin) | No |
PCI Express power connectors (6+2 pin) | 2 |
CPU power connector (4+4 pin) | Yes |
ATX Power connector (24-pin) | No |
ATX power connector (20+4 pin) | No |
Cabling type | Non-Modular |
EPS power connector (4+4 pin) | Yes |
Weight & dimensions | |
Width | 150 mm |
Depth | 140 mm |
Height | 86 mm |
Certificates | |
80 PLUS certification | 80 PLUS Bronze |
Logistics data | |
Harmonized System (HS) code | 84733020 |
Other features | |
Harmonized System (HS) code | 84733020 |
Cooling | |
---|---|
Fan diameter | 12 cm |
Number of fans | 1 fan(s) |
Cooling type | Active |
Performance | |
On/off switch | Yes |
Power supply unit (PSU) form factor | ATX |
80 PLUS certification | 80 PLUS Bronze |
Purpose | PC |
Harmonized System (HS) code | 84733020 |
Design | |
80 PLUS certification | 80 PLUS Bronze |
Product colour | Black |
Fan diameter | 12 cm |
On/off switch | Yes |
Number of fans | 1 fan(s) |
Cooling type | Active |
Power | |
Total power | 550 W |
Maximum input current (@220V) | 4 A |
AC input voltage | 100 - 240 V |
Power Factor Correction (PFC) type | Active |
Maximum input current (@110V) | 8 A |
Combined power (+3.3V) | 110 W |
Combined power (+12V) | 546 W |
Combined power (+5V) | 110 W |
Combined power (-12V) | 3.6 W |
Combined power (+5Vsb) | 12.5 W |
Max output current (+3.3V) | 20 A |
Max output current (+12V) | 45.5 A |
Max output current (+5V) | 20 A |
Max output current (-12V) | 0.3 A |
Max output current (+5Vsb) | 2.5 A |
Power protection features | Over current, Over power, Over voltage, Overheating, Short circuit |
Efficiency | 85% |
Ports & interfaces | |
Motherboard power cable length | 60 cm |
Motherboard power connector | 20+4 pin ATX |
Number of SATA power connectors | 5 |
Peripheral (Molex) power connectors (4-pin) | 2 |
EPS power connector (8-pin) | No |
PCI Express power connectors (6+2 pin) | 2 |
CPU power connector (4+4 pin) | Yes |
ATX Power connector (24-pin) | No |
ATX power connector (20+4 pin) | No |
Cabling type | Non-Modular |
EPS power connector (4+4 pin) | Yes |
Weight & dimensions | |
Width | 150 mm |
Depth | 140 mm |
Height | 86 mm |
Certificates | |
80 PLUS certification | 80 PLUS Bronze |
Logistics data | |
Harmonized System (HS) code | 84733020 |
Other features | |
Harmonized System (HS) code | 84733020 |
