Cooling | |
---|---|
Fan diameter | 13.5 cm |
Number of fans | 1 fan(s) |
Performance | |
On/off switch | Yes |
80 PLUS certification | 80 PLUS Gold |
Purpose | PC |
Mean time between failures (MTBF) | 100000 h |
Certification | TUV, CB, CE, FCC, RCM, cTUVus, WEEE, RoHS |
Bearing technology | FDB |
Design | |
80 PLUS certification | 80 PLUS Gold |
Certification | TUV, CB, CE, FCC, RCM, cTUVus, WEEE, RoHS |
Product colour | Black |
Fan diameter | 13.5 cm |
On/off switch | Yes |
Number of fans | 1 fan(s) |
Power | |
Total power | 650 W |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
Input current | 4.5 - 9 A |
Power Factor Correction (PFC) type | Active |
Combined power (+3.3V) | 120 W |
Combined power (+12V) | 650 W |
Combined power (+5V) | 120 W |
Combined power (-12V) | 6 W |
Combined power (+5Vsb) | 15 W |
Max output current (+3.3V) | 24 A |
Max output current (+12V) | 54.1 A |
Max output current (+5V) | 24 A |
Max output current (-12V) | 0.5 A |
Max output current (+5Vsb) | 3 A |
Power protection features | Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage |
Efficiency | 92% |
Ports & interfaces | |
Motherboard power cable length | 60 cm |
SATA power cable length | 550,650,750 mm |
Peripheral (Molex) power cable length | 550,650,750,850 mm |
PCI Express power cable length | 82 cm |
Floppy disk drive cable length | 10 cm |
Motherboard power connector | 24-pin ATX |
Number of SATA power connectors | 6 |
Peripheral (Molex) power connectors (4-pin) | 4 |
PCI Express power connectors (6+2 pin) | 3 |
Floppy drive power connector | 1 |
ATX Power connector (24-pin) | Yes |
Cabling type | Fully-Modular |
EPS power connector (4+4 pin) | Yes |
Operational conditions | |
Operating temperature (T-T) | 0 - 50 °C |
Weight & dimensions | |
Width | 150 mm |
Depth | 140 mm |
Height | 86 mm |
Weight | 2.72 kg |
Packaging data | |
Package type | Box |
Certificates | |
80 PLUS certification | 80 PLUS Gold |
Certification | TUV, CB, CE, FCC, RCM, cTUVus, WEEE, RoHS |
Cooling | |
---|---|
Fan diameter | 13.5 cm |
Number of fans | 1 fan(s) |
Performance | |
On/off switch | Yes |
80 PLUS certification | 80 PLUS Gold |
Purpose | PC |
Mean time between failures (MTBF) | 100000 h |
Certification | TUV, CB, CE, FCC, RCM, cTUVus, WEEE, RoHS |
Bearing technology | FDB |
Design | |
80 PLUS certification | 80 PLUS Gold |
Certification | TUV, CB, CE, FCC, RCM, cTUVus, WEEE, RoHS |
Product colour | Black |
Fan diameter | 13.5 cm |
On/off switch | Yes |
Number of fans | 1 fan(s) |
Power | |
Total power | 650 W |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
Input current | 4.5 - 9 A |
Power Factor Correction (PFC) type | Active |
Combined power (+3.3V) | 120 W |
Combined power (+12V) | 650 W |
Combined power (+5V) | 120 W |
Combined power (-12V) | 6 W |
Combined power (+5Vsb) | 15 W |
Max output current (+3.3V) | 24 A |
Max output current (+12V) | 54.1 A |
Max output current (+5V) | 24 A |
Max output current (-12V) | 0.5 A |
Max output current (+5Vsb) | 3 A |
Power protection features | Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage |
Efficiency | 92% |
Ports & interfaces | |
Motherboard power cable length | 60 cm |
SATA power cable length | 550,650,750 mm |
Peripheral (Molex) power cable length | 550,650,750,850 mm |
PCI Express power cable length | 82 cm |
Floppy disk drive cable length | 10 cm |
Motherboard power connector | 24-pin ATX |
Number of SATA power connectors | 6 |
Peripheral (Molex) power connectors (4-pin) | 4 |
PCI Express power connectors (6+2 pin) | 3 |
Floppy drive power connector | 1 |
ATX Power connector (24-pin) | Yes |
Cabling type | Fully-Modular |
EPS power connector (4+4 pin) | Yes |
Operational conditions | |
Operating temperature (T-T) | 0 - 50 °C |
Weight & dimensions | |
Width | 150 mm |
Depth | 140 mm |
Height | 86 mm |
Weight | 2.72 kg |
Packaging data | |
Package type | Box |
Certificates | |
80 PLUS certification | 80 PLUS Gold |
Certification | TUV, CB, CE, FCC, RCM, cTUVus, WEEE, RoHS |
