Power | |
---|---|
Output power factor | 1 |
Output power | 1000 W |
Input operation voltage (min) | 159 V |
Input operation voltage (max) | 288 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 2430 J |
Maximum current | 10 A |
Emergency Power Off (EPO) | Yes |
Output power capacity | 1 kVA |
Power Factor Correction (PFC) type | Active |
Ports & interfaces | |
Cable length | 1.8 m |
Emergency Power Off (EPO) connector | Yes |
USB port | Yes |
Serial interface | Yes |
Serial interface type | RS-232 |
AC outlets quantity | 10 AC outlet(s) |
AC outlet types | C13 coupler |
Power plug | C14 coupler |
USB 2.0 ports quantity | 1 |
Serial ports quantity | 1 |
Ethernet LAN (RJ-45) ports | 2 |
Battery | |
Battery type | RBP0128 |
Number of batteries supported | 1 |
Battery technology | Sealed Lead Acid (VRLA) |
Battery recharge time | 3 h |
Typical backup time at half load | 21 min |
Typical backup time at full load | 7 min |
Hot-swap battery | Yes |
Performance | |
Audible alarm modes | Alarm when on battery, Fault, Low battery alarm, Overload alarm |
UPS topology | Line-Interactive |
Waveform | Pure sine |
Automatic Voltage Regulation (AVR) | Yes |
Number of output phases | 1 |
Number of input phases | 1 |
Response time | 4 ms |
LED indicators | Fault, Power, Status |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Surge protection features | Network |
Power protection features | Overload |
Noise level | 52.5 dB |
Audible alarm(s) | Yes |
Features | |
Output frequency | 50/60 Hz |
Web-based management | Yes |
Management protocols | SNMP/HTTP |
Country of origin | China |
Audible alarm modes | Alarm when on battery, Fault, Low battery alarm, Overload alarm |
UPS topology | Line-Interactive |
Waveform | Pure sine |
Automatic Voltage Regulation (AVR) | Yes |
Number of output phases | 1 |
Number of input phases | 1 |
Output power factor | 1 |
Response time | 4 ms |
Output power | 1000 W |
Input operation voltage (min) | 159 V |
Input operation voltage (max) | 288 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 2430 J |
Maximum current | 10 A |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Surge protection features | Network |
Emergency Power Off (EPO) | Yes |
Power protection features | Overload |
Noise level | 52.5 dB |
Audible alarm(s) | Yes |
Output power capacity | 1 kVA |
Power Factor Correction (PFC) type | Active |
Input frequency | 50/60 Hz |
Heat dissipation | 47.4 BTU/h |
Design | |
Country of origin | China |
Rack capacity | 2U |
Form factor | Rackmount/Tower |
LED indicators | Fault, Power, Status |
Product colour | Black |
Cooling type | Active |
Cable length | 1.8 m |
Built-in fan | Yes |
Housing material | Metal |
Control type | Buttons |
Display type | LCD |
Operational conditions | |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -15 - 45 °C |
Operating relative humidity (H-H) | 0 - 95% |
Storage relative humidity (H-H) | 0 - 95% |
Operating altitude | 0 - 3000 m |
Non-operating altitude | 0 - 15000 m |
Technical details | |
Output frequency | 50/60 Hz |
Sustainability compliance | Yes |
Sustainability certificates | ENERGY STAR |
Harmonized System (HS) code | 8504408590 |
Warranty period | 3 year(s) |
Compliance certificates | CE, Federal Communications Commission (FCC), RCM, RoHS, UKCA, UL, VCCI |
Certificates | |
Compliance certificates | CE, Federal Communications Commission (FCC), RCM, RoHS, UKCA, UL, VCCI |
Management features | |
Web-based management | Yes |
Management protocols | SNMP/HTTP |
Packaging content | |
Cables included | Serial, USB cable |
Rack mount kit | Yes |
Manual | Yes |
Cooling | |
Cooling type | Active |
Built-in fan | Yes |
Sustainability | |
Sustainability compliance | Yes |
Sustainability certificates | ENERGY STAR |
Weight & dimensions | |
Package width | 560 mm |
Package depth | 530 mm |
Package height | 275 mm |
Weight | 22.4 kg |
Width | 433 mm |
Package weight | 29 kg |
Height | 86.5 mm |
Depth | 412 mm |
Packaging data | |
Cables included | Serial, USB cable |
Rack mount kit | Yes |
Manual | Yes |
Package width | 560 mm |
Package depth | 530 mm |
Package height | 275 mm |
Package weight | 29 kg |
Logistics data | |
Country of origin | China |
Harmonized System (HS) code | 8504408590 |
Warranty period | 3 year(s) |
Other features | |
Battery type | RBP0128 |
Power | |
---|---|
Output power factor | 1 |
Output power | 1000 W |
Input operation voltage (min) | 159 V |
Input operation voltage (max) | 288 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 2430 J |
Maximum current | 10 A |
Emergency Power Off (EPO) | Yes |
Output power capacity | 1 kVA |
Power Factor Correction (PFC) type | Active |
Ports & interfaces | |
Cable length | 1.8 m |
Emergency Power Off (EPO) connector | Yes |
USB port | Yes |
Serial interface | Yes |
Serial interface type | RS-232 |
AC outlets quantity | 10 AC outlet(s) |
AC outlet types | C13 coupler |
Power plug | C14 coupler |
USB 2.0 ports quantity | 1 |
Serial ports quantity | 1 |
Ethernet LAN (RJ-45) ports | 2 |
Battery | |
Battery type | RBP0128 |
Number of batteries supported | 1 |
Battery technology | Sealed Lead Acid (VRLA) |
Battery recharge time | 3 h |
Typical backup time at half load | 21 min |
Typical backup time at full load | 7 min |
Hot-swap battery | Yes |
Performance | |
Audible alarm modes | Alarm when on battery, Fault, Low battery alarm, Overload alarm |
UPS topology | Line-Interactive |
Waveform | Pure sine |
Automatic Voltage Regulation (AVR) | Yes |
Number of output phases | 1 |
Number of input phases | 1 |
Response time | 4 ms |
LED indicators | Fault, Power, Status |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Surge protection features | Network |
Power protection features | Overload |
Noise level | 52.5 dB |
Audible alarm(s) | Yes |
Features | |
Output frequency | 50/60 Hz |
Web-based management | Yes |
Management protocols | SNMP/HTTP |
Country of origin | China |
Audible alarm modes | Alarm when on battery, Fault, Low battery alarm, Overload alarm |
UPS topology | Line-Interactive |
Waveform | Pure sine |
Automatic Voltage Regulation (AVR) | Yes |
Number of output phases | 1 |
Number of input phases | 1 |
Output power factor | 1 |
Response time | 4 ms |
Output power | 1000 W |
Input operation voltage (min) | 159 V |
Input operation voltage (max) | 288 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 2430 J |
Maximum current | 10 A |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Surge protection features | Network |
Emergency Power Off (EPO) | Yes |
Power protection features | Overload |
Noise level | 52.5 dB |
Audible alarm(s) | Yes |
Output power capacity | 1 kVA |
Power Factor Correction (PFC) type | Active |
Input frequency | 50/60 Hz |
Heat dissipation | 47.4 BTU/h |
Design | |
Country of origin | China |
Rack capacity | 2U |
Form factor | Rackmount/Tower |
LED indicators | Fault, Power, Status |
Product colour | Black |
Cooling type | Active |
Cable length | 1.8 m |
Built-in fan | Yes |
Housing material | Metal |
Control type | Buttons |
Display type | LCD |
Operational conditions | |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -15 - 45 °C |
Operating relative humidity (H-H) | 0 - 95% |
Storage relative humidity (H-H) | 0 - 95% |
Operating altitude | 0 - 3000 m |
Non-operating altitude | 0 - 15000 m |
Technical details | |
Output frequency | 50/60 Hz |
Sustainability compliance | Yes |
Sustainability certificates | ENERGY STAR |
Harmonized System (HS) code | 8504408590 |
Warranty period | 3 year(s) |
Compliance certificates | CE, Federal Communications Commission (FCC), RCM, RoHS, UKCA, UL, VCCI |
Certificates | |
Compliance certificates | CE, Federal Communications Commission (FCC), RCM, RoHS, UKCA, UL, VCCI |
Management features | |
Web-based management | Yes |
Management protocols | SNMP/HTTP |
Packaging content | |
Cables included | Serial, USB cable |
Rack mount kit | Yes |
Manual | Yes |
Cooling | |
Cooling type | Active |
Built-in fan | Yes |
Sustainability | |
Sustainability compliance | Yes |
Sustainability certificates | ENERGY STAR |
Weight & dimensions | |
Package width | 560 mm |
Package depth | 530 mm |
Package height | 275 mm |
Weight | 22.4 kg |
Width | 433 mm |
Package weight | 29 kg |
Height | 86.5 mm |
Depth | 412 mm |
Packaging data | |
Cables included | Serial, USB cable |
Rack mount kit | Yes |
Manual | Yes |
Package width | 560 mm |
Package depth | 530 mm |
Package height | 275 mm |
Package weight | 29 kg |
Logistics data | |
Country of origin | China |
Harmonized System (HS) code | 8504408590 |
Warranty period | 3 year(s) |
Other features | |
Battery type | RBP0128 |
Save £363.42
Power | |
---|---|
Output power factor | 1 |
Output power | 1500 W |
Input operation voltage (min) | 159 V |
Input operation voltage (max) | 288 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 2430 J |
Maximum current | 10 A |
Emergency Power Off (EPO) | Yes |
Output power capacity | 1.5 kVA |
Power Factor Correction (PFC) type | Active |
Ports & interfaces | |
Cable length | 3.05 m |
Emergency Power Off (EPO) connector | Yes |
USB port | Yes |
Serial interface | Yes |
Serial interface type | RS-232 |
AC outlets quantity | 10 AC outlet(s) |
AC outlet types | C13 coupler |
Power plug | C14 coupler |
USB 2.0 ports quantity | 1 |
Serial ports quantity | 1 |
RS-232 ports | 1 |
Ethernet LAN (RJ-45) ports | 2 |
Battery | |
Battery type | RBP0129 |
Number of batteries supported | 1 |
Battery technology | Sealed Lead Acid (VRLA) |
Battery recharge time | 3 h |
Typical backup time at half load | 18.6 min |
Typical backup time at full load | 6 min |
Hot-swap battery | Yes |
Performance | |
Audible alarm modes | Alarm when on battery, Fault, Low battery alarm, Overload alarm |
UPS topology | Line-Interactive |
Waveform | Pure sine |
Automatic Voltage Regulation (AVR) | Yes |
Number of output phases | 1 |
Number of input phases | 1 |
Response time | 4 ms |
LED indicators | Fault, Power, Status |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Surge protection features | Network |
Power protection features | Overload |
Noise level | 52.5 dB |
Audible alarm(s) | Yes |
Features | |
Output frequency | 50/60 Hz |
Management protocols | SNMP/HTTP |
Country of origin | China |
Audible alarm modes | Alarm when on battery, Fault, Low battery alarm, Overload alarm |
UPS topology | Line-Interactive |
Waveform | Pure sine |
Automatic Voltage Regulation (AVR) | Yes |
Number of output phases | 1 |
Number of input phases | 1 |
Output power factor | 1 |
Response time | 4 ms |
Output power | 1500 W |
Input operation voltage (min) | 159 V |
Input operation voltage (max) | 288 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 2430 J |
Maximum current | 10 A |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Surge protection features | Network |
Emergency Power Off (EPO) | Yes |
Power protection features | Overload |
Noise level | 52.5 dB |
Audible alarm(s) | Yes |
Output power capacity | 1.5 kVA |
Power Factor Correction (PFC) type | Active |
Input frequency | 50/60 Hz |
Heat dissipation | 75.1 BTU/h |
Design | |
Country of origin | China |
Rack capacity | 2U |
Form factor | Rackmount/Tower |
LED indicators | Fault, Power, Status |
Product colour | Black |
Cooling type | Active |
Cable length | 3.05 m |
Built-in fan | Yes |
Housing material | Metal |
Control type | Buttons |
Display type | LCD |
Operational conditions | |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -15 - 45 °C |
Operating relative humidity (H-H) | 0 - 95% |
Storage relative humidity (H-H) | 0 - 95% |
Operating altitude | 0 - 3000 m |
Non-operating altitude | 0 - 15000 m |
Technical details | |
Output frequency | 50/60 Hz |
Sustainability compliance | Yes |
Harmonized System (HS) code | 8504408590 |
Warranty period | 3 year(s) |
Compliance certificates | RoHS |
Certificates | |
Compliance certificates | RoHS |
Management features | |
Management protocols | SNMP/HTTP |
Packaging content | |
Cables included | Serial, USB cable |
Rack mount kit | Yes |
Manual | Yes |
Cooling | |
Cooling type | Active |
Built-in fan | Yes |
Sustainability | |
Sustainability compliance | Yes |
Weight & dimensions | |
Package width | 560 mm |
Package depth | 530 mm |
Package height | 275 mm |
Weight | 29.4 kg |
Width | 433 mm |
Package weight | 31.2 kg |
Height | 86.5 mm |
Depth | 412 mm |
Packaging data | |
Cables included | Serial, USB cable |
Rack mount kit | Yes |
Manual | Yes |
Package width | 560 mm |
Package depth | 530 mm |
Package height | 275 mm |
Package weight | 31.2 kg |
Logistics data | |
Country of origin | China |
Harmonized System (HS) code | 8504408590 |
Warranty period | 3 year(s) |
Other features | |
Battery type | RBP0129 |
Power | |
---|---|
Output power factor | 1 |
Output power | 1500 W |
Input operation voltage (min) | 159 V |
Input operation voltage (max) | 288 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 2430 J |
Maximum current | 10 A |
Emergency Power Off (EPO) | Yes |
Output power capacity | 1.5 kVA |
Power Factor Correction (PFC) type | Active |
Ports & interfaces | |
Cable length | 3.05 m |
Emergency Power Off (EPO) connector | Yes |
USB port | Yes |
Serial interface | Yes |
Serial interface type | RS-232 |
AC outlets quantity | 10 AC outlet(s) |
AC outlet types | C13 coupler |
Power plug | C14 coupler |
USB 2.0 ports quantity | 1 |
Serial ports quantity | 1 |
RS-232 ports | 1 |
Ethernet LAN (RJ-45) ports | 2 |
Battery | |
Battery type | RBP0129 |
Number of batteries supported | 1 |
Battery technology | Sealed Lead Acid (VRLA) |
Battery recharge time | 3 h |
Typical backup time at half load | 18.6 min |
Typical backup time at full load | 6 min |
Hot-swap battery | Yes |
Performance | |
Audible alarm modes | Alarm when on battery, Fault, Low battery alarm, Overload alarm |
UPS topology | Line-Interactive |
Waveform | Pure sine |
Automatic Voltage Regulation (AVR) | Yes |
Number of output phases | 1 |
Number of input phases | 1 |
Response time | 4 ms |
LED indicators | Fault, Power, Status |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Surge protection features | Network |
Power protection features | Overload |
Noise level | 52.5 dB |
Audible alarm(s) | Yes |
Features | |
Output frequency | 50/60 Hz |
Management protocols | SNMP/HTTP |
Country of origin | China |
Audible alarm modes | Alarm when on battery, Fault, Low battery alarm, Overload alarm |
UPS topology | Line-Interactive |
Waveform | Pure sine |
Automatic Voltage Regulation (AVR) | Yes |
Number of output phases | 1 |
Number of input phases | 1 |
Output power factor | 1 |
Response time | 4 ms |
Output power | 1500 W |
Input operation voltage (min) | 159 V |
Input operation voltage (max) | 288 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 2430 J |
Maximum current | 10 A |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Surge protection features | Network |
Emergency Power Off (EPO) | Yes |
Power protection features | Overload |
Noise level | 52.5 dB |
Audible alarm(s) | Yes |
Output power capacity | 1.5 kVA |
Power Factor Correction (PFC) type | Active |
Input frequency | 50/60 Hz |
Heat dissipation | 75.1 BTU/h |
Design | |
Country of origin | China |
Rack capacity | 2U |
Form factor | Rackmount/Tower |
LED indicators | Fault, Power, Status |
Product colour | Black |
Cooling type | Active |
Cable length | 3.05 m |
Built-in fan | Yes |
Housing material | Metal |
Control type | Buttons |
Display type | LCD |
Operational conditions | |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -15 - 45 °C |
Operating relative humidity (H-H) | 0 - 95% |
Storage relative humidity (H-H) | 0 - 95% |
Operating altitude | 0 - 3000 m |
Non-operating altitude | 0 - 15000 m |
Technical details | |
Output frequency | 50/60 Hz |
Sustainability compliance | Yes |
Harmonized System (HS) code | 8504408590 |
Warranty period | 3 year(s) |
Compliance certificates | RoHS |
Certificates | |
Compliance certificates | RoHS |
Management features | |
Management protocols | SNMP/HTTP |
Packaging content | |
Cables included | Serial, USB cable |
Rack mount kit | Yes |
Manual | Yes |
Cooling | |
Cooling type | Active |
Built-in fan | Yes |
Sustainability | |
Sustainability compliance | Yes |
Weight & dimensions | |
Package width | 560 mm |
Package depth | 530 mm |
Package height | 275 mm |
Weight | 29.4 kg |
Width | 433 mm |
Package weight | 31.2 kg |
Height | 86.5 mm |
Depth | 412 mm |
Packaging data | |
Cables included | Serial, USB cable |
Rack mount kit | Yes |
Manual | Yes |
Package width | 560 mm |
Package depth | 530 mm |
Package height | 275 mm |
Package weight | 31.2 kg |
Logistics data | |
Country of origin | China |
Harmonized System (HS) code | 8504408590 |
Warranty period | 3 year(s) |
Other features | |
Battery type | RBP0129 |
Save £360.11
Power | |
---|---|
Output power | 3000 W |
Input operation voltage (min) | 159 V |
Input operation voltage (max) | 288 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 2430 J |
Maximum current | 16 A |
Power factor | 1 |
Output power capacity | 3 kVA |
Power Factor Correction (PFC) type | Active |
Ports & interfaces | |
Cable length | 2.4 m |
Socket circuit breaker | Yes |
Emergency Power Off (EPO) connector | Yes |
USB port | Yes |
Serial interface | Yes |
Serial interface type | RS-232 |
Cabling technology | 10/100/1000Base-T(X) |
AC outlets quantity | 8 AC outlet(s) |
AC outlet types | C13 coupler, C19 coupler |
Power plug | C20 coupler |
Ethernet LAN (RJ-45) ports | 2 |
Performance | |
Audible alarm modes | Alarm when on battery, Low battery alarm, Overload alarm |
UPS topology | Line-Interactive |
Waveform | Pure sine |
Automatic Voltage Regulation (AVR) | Yes |
Number of input phases | 1 |
Response time | 4 ms |
LED indicators | Error, Operation |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Power protection features | Overload, Short circuit |
Audible alarm(s) | Yes |
Transfer time (Line Mode to Battery Mode) | 4 ms |
Features | |
Output frequency | 50/60 Hz |
Web-based management | Yes |
Management protocols | SNMP/HTTP |
Country of origin | China |
Audible alarm modes | Alarm when on battery, Low battery alarm, Overload alarm |
UPS topology | Line-Interactive |
Waveform | Pure sine |
Automatic Voltage Regulation (AVR) | Yes |
Number of input phases | 1 |
Response time | 4 ms |
Output power | 3000 W |
Input operation voltage (min) | 159 V |
Input operation voltage (max) | 288 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 2430 J |
Maximum current | 16 A |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Power protection features | Overload, Short circuit |
Power factor | 1 |
Audible alarm(s) | Yes |
Output power capacity | 3 kVA |
Power Factor Correction (PFC) type | Active |
Socket circuit breaker | Yes |
Transfer time (Line Mode to Battery Mode) | 4 ms |
Input frequency | 50/60 Hz |
Battery | |
Number of batteries supported | 4 |
Battery technology | Sealed Lead Acid (VRLA) |
Battery recharge time | 3 h |
Typical backup time at half load | 7.1 min |
Typical backup time at full load | 1.7 min |
Hot-swap battery | Yes |
Replacement battery cartridge | RBP0129 |
Design | |
Country of origin | China |
Rack capacity | 2U |
Form factor | Rackmount/Tower |
LED indicators | Error, Operation |
Product colour | Black |
Certification | CE , FCC Class A , UL , CISPR 22 Class A , IEC62040-2 , RCM , VCCI , EN 61000-3-2 |
Cable length | 2.4 m |
Housing material | Metal |
Display type | LCD |
Operational conditions | |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -15 - 45 °C |
Operating relative humidity (H-H) | 0 - 95% |
Storage relative humidity (H-H) | 0 - 95% |
Operating altitude | 0 - 3000 m |
Non-operating altitude | 0 - 15000 m |
Technical details | |
Output frequency | 50/60 Hz |
Bypass | GreenPower UPS |
Sustainability certificates | ENERGY STAR |
Harmonized System (HS) code | 8504408590 |
Compliance certificates | RoHS |
Management features | |
Web-based management | Yes |
Management protocols | SNMP/HTTP |
Weight & dimensions | |
Package width | 560 mm |
Package depth | 620 mm |
Package height | 275 mm |
Weight | 32.8 kg |
Width | 433 mm |
Package weight | 41 kg |
Height | 86.5 mm |
Depth | 500 mm |
Package volume | 40800 cm³ |
Packaging data | |
Package volume | 40800 cm³ |
Package width | 560 mm |
Package depth | 620 mm |
Package height | 275 mm |
Package weight | 41 kg |
Logistics data | |
Harmonized System (HS) code | 8504408590 |
Certificates | |
Certification | CE , FCC Class A , UL , CISPR 22 Class A , IEC62040-2 , RCM , VCCI , EN 61000-3-2 |
Other features | |
Bypass | GreenPower UPS |
Power | |
---|---|
Output power | 3000 W |
Input operation voltage (min) | 159 V |
Input operation voltage (max) | 288 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 2430 J |
Maximum current | 16 A |
Power factor | 1 |
Output power capacity | 3 kVA |
Power Factor Correction (PFC) type | Active |
Ports & interfaces | |
Cable length | 2.4 m |
Socket circuit breaker | Yes |
Emergency Power Off (EPO) connector | Yes |
USB port | Yes |
Serial interface | Yes |
Serial interface type | RS-232 |
Cabling technology | 10/100/1000Base-T(X) |
AC outlets quantity | 8 AC outlet(s) |
AC outlet types | C13 coupler, C19 coupler |
Power plug | C20 coupler |
Ethernet LAN (RJ-45) ports | 2 |
Performance | |
Audible alarm modes | Alarm when on battery, Low battery alarm, Overload alarm |
UPS topology | Line-Interactive |
Waveform | Pure sine |
Automatic Voltage Regulation (AVR) | Yes |
Number of input phases | 1 |
Response time | 4 ms |
LED indicators | Error, Operation |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Power protection features | Overload, Short circuit |
Audible alarm(s) | Yes |
Transfer time (Line Mode to Battery Mode) | 4 ms |
Features | |
Output frequency | 50/60 Hz |
Web-based management | Yes |
Management protocols | SNMP/HTTP |
Country of origin | China |
Audible alarm modes | Alarm when on battery, Low battery alarm, Overload alarm |
UPS topology | Line-Interactive |
Waveform | Pure sine |
Automatic Voltage Regulation (AVR) | Yes |
Number of input phases | 1 |
Response time | 4 ms |
Output power | 3000 W |
Input operation voltage (min) | 159 V |
Input operation voltage (max) | 288 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 2430 J |
Maximum current | 16 A |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Power protection features | Overload, Short circuit |
Power factor | 1 |
Audible alarm(s) | Yes |
Output power capacity | 3 kVA |
Power Factor Correction (PFC) type | Active |
Socket circuit breaker | Yes |
Transfer time (Line Mode to Battery Mode) | 4 ms |
Input frequency | 50/60 Hz |
Battery | |
Number of batteries supported | 4 |
Battery technology | Sealed Lead Acid (VRLA) |
Battery recharge time | 3 h |
Typical backup time at half load | 7.1 min |
Typical backup time at full load | 1.7 min |
Hot-swap battery | Yes |
Replacement battery cartridge | RBP0129 |
Design | |
Country of origin | China |
Rack capacity | 2U |
Form factor | Rackmount/Tower |
LED indicators | Error, Operation |
Product colour | Black |
Certification | CE , FCC Class A , UL , CISPR 22 Class A , IEC62040-2 , RCM , VCCI , EN 61000-3-2 |
Cable length | 2.4 m |
Housing material | Metal |
Display type | LCD |
Operational conditions | |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -15 - 45 °C |
Operating relative humidity (H-H) | 0 - 95% |
Storage relative humidity (H-H) | 0 - 95% |
Operating altitude | 0 - 3000 m |
Non-operating altitude | 0 - 15000 m |
Technical details | |
Output frequency | 50/60 Hz |
Bypass | GreenPower UPS |
Sustainability certificates | ENERGY STAR |
Harmonized System (HS) code | 8504408590 |
Compliance certificates | RoHS |
Management features | |
Web-based management | Yes |
Management protocols | SNMP/HTTP |
Weight & dimensions | |
Package width | 560 mm |
Package depth | 620 mm |
Package height | 275 mm |
Weight | 32.8 kg |
Width | 433 mm |
Package weight | 41 kg |
Height | 86.5 mm |
Depth | 500 mm |
Package volume | 40800 cm³ |
Packaging data | |
Package volume | 40800 cm³ |
Package width | 560 mm |
Package depth | 620 mm |
Package height | 275 mm |
Package weight | 41 kg |
Logistics data | |
Harmonized System (HS) code | 8504408590 |
Certificates | |
Certification | CE , FCC Class A , UL , CISPR 22 Class A , IEC62040-2 , RCM , VCCI , EN 61000-3-2 |
Other features | |
Bypass | GreenPower UPS |
Save £452.06
Power | |
---|---|
Output power | 2200 W |
Input operation voltage (min) | 159 V |
Input operation voltage (max) | 288 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 2430 J |
Power factor | 1 |
Output power capacity | 2.2 kVA |
Power Factor Correction (PFC) type | Active |
Ports & interfaces | |
Cable length | 2.4 m |
Socket circuit breaker | Yes |
Emergency Power Off (EPO) connector | Yes |
USB port | Yes |
Serial interface | Yes |
Serial interface type | RS-232 |
AC outlets quantity | 8 AC outlet(s) |
AC outlet types | C13 coupler, C19 coupler |
Power plug | C20 coupler |
Ethernet LAN (RJ-45) ports | 2 |
Performance | |
Audible alarm modes | Alarm when on battery, Low battery alarm |
UPS topology | Line-Interactive |
Waveform | Pure sine |
Automatic Voltage Regulation (AVR) | Yes |
Number of input phases | 1 |
LED indicators | Yes |
EMI/RFI noise filtering | Yes |
Power protection features | Overload, Short circuit |
Noise level | 52.5 dB |
Audible alarm(s) | Yes |
Transfer time (Line Mode to Battery Mode) | 4 ms |
Features | |
Web-based management | Yes |
Audible alarm modes | Alarm when on battery, Low battery alarm |
UPS topology | Line-Interactive |
Waveform | Pure sine |
Automatic Voltage Regulation (AVR) | Yes |
Number of input phases | 1 |
Output power | 2200 W |
Input operation voltage (min) | 159 V |
Input operation voltage (max) | 288 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 2430 J |
EMI/RFI noise filtering | Yes |
Power protection features | Overload, Short circuit |
Power factor | 1 |
Noise level | 52.5 dB |
Audible alarm(s) | Yes |
Output power capacity | 2.2 kVA |
Power Factor Correction (PFC) type | Active |
Socket circuit breaker | Yes |
Transfer time (Line Mode to Battery Mode) | 4 ms |
Input frequency | 50/60 Hz |
Battery | |
Number of batteries supported | 1 |
Battery technology | Sealed Lead Acid (VRLA) |
Battery recharge time | 3 h |
Typical backup time at half load | 11.4 min |
Typical backup time at full load | 3 min |
Hot-swap battery | Yes |
Design | |
Rack capacity | 2U |
Form factor | Rackmount/Tower |
LED indicators | Yes |
Product colour | Black |
Certification | CE , FCC Class B , UL , RCM , VCCI |
Cable length | 2.4 m |
Housing material | Metal |
Display type | LCD |
Operational conditions | |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -15 - 45 °C |
Operating relative humidity (H-H) | 0 - 95% |
Storage relative humidity (H-H) | 0 - 95% |
Operating altitude | 0 - 3000 m |
Non-operating altitude | 0 - 15000 m |
Technical details | |
Bypass | GreenPower UPS |
Sustainability certificates | ENERGY STAR |
Compliance certificates | RoHS |
Management features | |
Web-based management | Yes |
Weight & dimensions | |
Package width | 560 mm |
Package depth | 530 mm |
Package height | 275 mm |
Weight | 25.7 kg |
Width | 433 mm |
Package weight | 33.5 kg |
Height | 86.5 mm |
Depth | 412 mm |
Packaging data | |
Package width | 560 mm |
Package depth | 530 mm |
Package height | 275 mm |
Package weight | 33.5 kg |
Certificates | |
Certification | CE , FCC Class B , UL , RCM , VCCI |
Other features | |
Bypass | GreenPower UPS |
Power | |
---|---|
Output power | 2200 W |
Input operation voltage (min) | 159 V |
Input operation voltage (max) | 288 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 2430 J |
Power factor | 1 |
Output power capacity | 2.2 kVA |
Power Factor Correction (PFC) type | Active |
Ports & interfaces | |
Cable length | 2.4 m |
Socket circuit breaker | Yes |
Emergency Power Off (EPO) connector | Yes |
USB port | Yes |
Serial interface | Yes |
Serial interface type | RS-232 |
AC outlets quantity | 8 AC outlet(s) |
AC outlet types | C13 coupler, C19 coupler |
Power plug | C20 coupler |
Ethernet LAN (RJ-45) ports | 2 |
Performance | |
Audible alarm modes | Alarm when on battery, Low battery alarm |
UPS topology | Line-Interactive |
Waveform | Pure sine |
Automatic Voltage Regulation (AVR) | Yes |
Number of input phases | 1 |
LED indicators | Yes |
EMI/RFI noise filtering | Yes |
Power protection features | Overload, Short circuit |
Noise level | 52.5 dB |
Audible alarm(s) | Yes |
Transfer time (Line Mode to Battery Mode) | 4 ms |
Features | |
Web-based management | Yes |
Audible alarm modes | Alarm when on battery, Low battery alarm |
UPS topology | Line-Interactive |
Waveform | Pure sine |
Automatic Voltage Regulation (AVR) | Yes |
Number of input phases | 1 |
Output power | 2200 W |
Input operation voltage (min) | 159 V |
Input operation voltage (max) | 288 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 2430 J |
EMI/RFI noise filtering | Yes |
Power protection features | Overload, Short circuit |
Power factor | 1 |
Noise level | 52.5 dB |
Audible alarm(s) | Yes |
Output power capacity | 2.2 kVA |
Power Factor Correction (PFC) type | Active |
Socket circuit breaker | Yes |
Transfer time (Line Mode to Battery Mode) | 4 ms |
Input frequency | 50/60 Hz |
Battery | |
Number of batteries supported | 1 |
Battery technology | Sealed Lead Acid (VRLA) |
Battery recharge time | 3 h |
Typical backup time at half load | 11.4 min |
Typical backup time at full load | 3 min |
Hot-swap battery | Yes |
Design | |
Rack capacity | 2U |
Form factor | Rackmount/Tower |
LED indicators | Yes |
Product colour | Black |
Certification | CE , FCC Class B , UL , RCM , VCCI |
Cable length | 2.4 m |
Housing material | Metal |
Display type | LCD |
Operational conditions | |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -15 - 45 °C |
Operating relative humidity (H-H) | 0 - 95% |
Storage relative humidity (H-H) | 0 - 95% |
Operating altitude | 0 - 3000 m |
Non-operating altitude | 0 - 15000 m |
Technical details | |
Bypass | GreenPower UPS |
Sustainability certificates | ENERGY STAR |
Compliance certificates | RoHS |
Management features | |
Web-based management | Yes |
Weight & dimensions | |
Package width | 560 mm |
Package depth | 530 mm |
Package height | 275 mm |
Weight | 25.7 kg |
Width | 433 mm |
Package weight | 33.5 kg |
Height | 86.5 mm |
Depth | 412 mm |
Packaging data | |
Package width | 560 mm |
Package depth | 530 mm |
Package height | 275 mm |
Package weight | 33.5 kg |
Certificates | |
Certification | CE , FCC Class B , UL , RCM , VCCI |
Other features | |
Bypass | GreenPower UPS |
Save £321.07
Power | |
---|---|
Output power | 2200 W |
Input operation voltage (min) | 159 V |
Input operation voltage (max) | 288 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 2430 J |
Maximum current | 16 A |
Output power capacity | 2.2 kVA |
Power Factor Correction (PFC) type | Active |
Ports & interfaces | |
Cable length | 2.4 m |
Emergency Power Off (EPO) connector | Yes |
USB port | Yes |
Serial interface | Yes |
Serial interface type | RS-232 |
AC outlets quantity | 8 AC outlet(s) |
AC outlet types | C13 coupler, C19 coupler |
Power plug | C20 coupler |
USB 2.0 ports quantity | 1 |
Serial ports quantity | 1 |
Ethernet LAN (RJ-45) ports | 2 |
Performance | |
Audible alarm modes | Alarm when on battery, Low battery alarm, Overload alarm |
UPS topology | Line-Interactive |
Waveform | Pure sine |
Automatic Voltage Regulation (AVR) | Yes |
Number of input phases | 1 |
Response time | 4 ms |
LED indicators | Error, Operation |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Power protection features | Overload |
Noise level | 57.5 dB |
Audible alarm(s) | Yes |
Features | |
Output frequency | 50/60 Hz |
Management protocols | SNMP/HTTP |
Country of origin | China |
Audible alarm modes | Alarm when on battery, Low battery alarm, Overload alarm |
UPS topology | Line-Interactive |
Waveform | Pure sine |
Automatic Voltage Regulation (AVR) | Yes |
Number of input phases | 1 |
Response time | 4 ms |
Output power | 2200 W |
Input operation voltage (min) | 159 V |
Input operation voltage (max) | 288 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 2430 J |
Maximum current | 16 A |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Power protection features | Overload |
Noise level | 57.5 dB |
Audible alarm(s) | Yes |
Output power capacity | 2.2 kVA |
Power Factor Correction (PFC) type | Active |
Input frequency | 50/60 Hz |
Battery | |
Number of batteries supported | 4 |
Battery technology | Sealed Lead Acid (VRLA) |
Typical backup time at half load | 11.2 min |
Typical backup time at full load | 3.2 min |
Hot-swap battery | Yes |
Design | |
Country of origin | China |
Rack capacity | 2U |
Form factor | Rackmount/Tower |
LED indicators | Error, Operation |
Product colour | Black |
Certification | CE , FCC Class B , UL , RCM , VCCI |
Cable length | 2.4 m |
Housing material | Metal |
Display type | LCD |
Operational conditions | |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -15 - 45 °C |
Operating relative humidity (H-H) | 0 - 95% |
Storage relative humidity (H-H) | 0 - 95% |
Operating altitude | 0 - 3000 m |
Non-operating altitude | 0 - 15000 m |
Technical details | |
Output frequency | 50/60 Hz |
Bypass | GreenPower UPS |
Sustainability certificates | ENERGY STAR |
Harmonized System (HS) code | 8504408590 |
Compliance certificates | RoHS |
Management features | |
Management protocols | SNMP/HTTP |
Weight & dimensions | |
Package width | 560 mm |
Package depth | 620 mm |
Package height | 275 mm |
Weight | 34.4 kg |
Width | 433 mm |
Package weight | 42.5 kg |
Height | 86.5 mm |
Depth | 500 mm |
Packaging data | |
Cables included | Serial, USB cable |
Package width | 560 mm |
Package depth | 620 mm |
Package height | 275 mm |
Package weight | 42.5 kg |
Logistics data | |
Harmonized System (HS) code | 8504408590 |
Certificates | |
Certification | CE , FCC Class B , UL , RCM , VCCI |
Other features | |
Bypass | GreenPower UPS |
Packaging content | |
Cables included | Serial, USB cable |
Power | |
---|---|
Output power | 2200 W |
Input operation voltage (min) | 159 V |
Input operation voltage (max) | 288 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 2430 J |
Maximum current | 16 A |
Output power capacity | 2.2 kVA |
Power Factor Correction (PFC) type | Active |
Ports & interfaces | |
Cable length | 2.4 m |
Emergency Power Off (EPO) connector | Yes |
USB port | Yes |
Serial interface | Yes |
Serial interface type | RS-232 |
AC outlets quantity | 8 AC outlet(s) |
AC outlet types | C13 coupler, C19 coupler |
Power plug | C20 coupler |
USB 2.0 ports quantity | 1 |
Serial ports quantity | 1 |
Ethernet LAN (RJ-45) ports | 2 |
Performance | |
Audible alarm modes | Alarm when on battery, Low battery alarm, Overload alarm |
UPS topology | Line-Interactive |
Waveform | Pure sine |
Automatic Voltage Regulation (AVR) | Yes |
Number of input phases | 1 |
Response time | 4 ms |
LED indicators | Error, Operation |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Power protection features | Overload |
Noise level | 57.5 dB |
Audible alarm(s) | Yes |
Features | |
Output frequency | 50/60 Hz |
Management protocols | SNMP/HTTP |
Country of origin | China |
Audible alarm modes | Alarm when on battery, Low battery alarm, Overload alarm |
UPS topology | Line-Interactive |
Waveform | Pure sine |
Automatic Voltage Regulation (AVR) | Yes |
Number of input phases | 1 |
Response time | 4 ms |
Output power | 2200 W |
Input operation voltage (min) | 159 V |
Input operation voltage (max) | 288 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 2430 J |
Maximum current | 16 A |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Power protection features | Overload |
Noise level | 57.5 dB |
Audible alarm(s) | Yes |
Output power capacity | 2.2 kVA |
Power Factor Correction (PFC) type | Active |
Input frequency | 50/60 Hz |
Battery | |
Number of batteries supported | 4 |
Battery technology | Sealed Lead Acid (VRLA) |
Typical backup time at half load | 11.2 min |
Typical backup time at full load | 3.2 min |
Hot-swap battery | Yes |
Design | |
Country of origin | China |
Rack capacity | 2U |
Form factor | Rackmount/Tower |
LED indicators | Error, Operation |
Product colour | Black |
Certification | CE , FCC Class B , UL , RCM , VCCI |
Cable length | 2.4 m |
Housing material | Metal |
Display type | LCD |
Operational conditions | |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -15 - 45 °C |
Operating relative humidity (H-H) | 0 - 95% |
Storage relative humidity (H-H) | 0 - 95% |
Operating altitude | 0 - 3000 m |
Non-operating altitude | 0 - 15000 m |
Technical details | |
Output frequency | 50/60 Hz |
Bypass | GreenPower UPS |
Sustainability certificates | ENERGY STAR |
Harmonized System (HS) code | 8504408590 |
Compliance certificates | RoHS |
Management features | |
Management protocols | SNMP/HTTP |
Weight & dimensions | |
Package width | 560 mm |
Package depth | 620 mm |
Package height | 275 mm |
Weight | 34.4 kg |
Width | 433 mm |
Package weight | 42.5 kg |
Height | 86.5 mm |
Depth | 500 mm |
Packaging data | |
Cables included | Serial, USB cable |
Package width | 560 mm |
Package depth | 620 mm |
Package height | 275 mm |
Package weight | 42.5 kg |
Logistics data | |
Harmonized System (HS) code | 8504408590 |
Certificates | |
Certification | CE , FCC Class B , UL , RCM , VCCI |
Other features | |
Bypass | GreenPower UPS |
Packaging content | |
Cables included | Serial, USB cable |
Save £386.54
Power | |
---|---|
Output power | 3000 W |
Input operation voltage (min) | 159 V |
Input operation voltage (max) | 288 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 2430 J |
Maximum current | 10 A |
Emergency Power Off (EPO) | Yes |
Power factor | 1 |
Output power capacity | 3 kVA |
Power Factor Correction (PFC) type | Active |
Ports & interfaces | |
Cable length | 2.4 m |
Emergency Power Off (EPO) connector | Yes |
USB port | Yes |
Serial interface | Yes |
Serial interface type | RS-232 |
AC outlets quantity | 8 AC outlet(s) |
AC outlet types | C13 coupler, C19 coupler |
Power plug | C20 coupler |
Serial ports quantity | 1 |
RS-232 ports | 1 |
Ethernet LAN (RJ-45) ports | 2 |
Battery | |
Battery type | RBP0129 |
Number of batteries supported | 1 |
Battery technology | Sealed Lead Acid (VRLA) |
Battery recharge time | 3 h |
Typical backup time at half load | 6.4 min |
Typical backup time at full load | 1.3 min |
Hot-swap battery | Yes |
Performance | |
Audible alarm modes | Alarm when on battery, Fault, Low battery alarm, Overload alarm |
UPS topology | Line-Interactive |
Waveform | Pure sine |
Automatic Voltage Regulation (AVR) | Yes |
Number of output phases | 1 |
Number of input phases | 1 |
Response time | 4 ms |
LED indicators | Fault, Power, Status |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Surge protection features | Network |
Power protection features | Overload |
Noise level | 57.5 dB |
Audible alarm(s) | Yes |
Features | |
Output frequency | 50/60 Hz |
Management protocols | SNMP/HTTP |
Country of origin | China |
Audible alarm modes | Alarm when on battery, Fault, Low battery alarm, Overload alarm |
UPS topology | Line-Interactive |
Waveform | Pure sine |
Automatic Voltage Regulation (AVR) | Yes |
Number of output phases | 1 |
Number of input phases | 1 |
Response time | 4 ms |
Output power | 3000 W |
Input operation voltage (min) | 159 V |
Input operation voltage (max) | 288 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 2430 J |
Maximum current | 10 A |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Surge protection features | Network |
Emergency Power Off (EPO) | Yes |
Power protection features | Overload |
Power factor | 1 |
Noise level | 57.5 dB |
Audible alarm(s) | Yes |
Output power capacity | 3 kVA |
Power Factor Correction (PFC) type | Active |
Input frequency | 50/60 Hz |
Heat dissipation | 120.8 BTU/h |
Design | |
Country of origin | China |
Rack capacity | 2U |
Form factor | Rackmount/Tower |
LED indicators | Fault, Power, Status |
Product colour | Black |
Cooling type | Active |
Cable length | 2.4 m |
Built-in fan | Yes |
Housing material | Metal |
Control type | Buttons |
Display type | LCD |
Operational conditions | |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -15 - 45 °C |
Operating relative humidity (H-H) | 0 - 95% |
Storage relative humidity (H-H) | 0 - 95% |
Operating altitude | 0 - 3000 m |
Non-operating altitude | 0 - 15000 m |
Technical details | |
Output frequency | 50/60 Hz |
Sustainability compliance | Yes |
Sustainability certificates | ENERGY STAR |
Harmonized System (HS) code | 8504408590 |
Warranty period | 3 year(s) |
Compliance certificates | RoHS |
Certificates | |
Compliance certificates | RoHS |
Management features | |
Management protocols | SNMP/HTTP |
Packaging content | |
Cables included | Serial, USB cable |
Rack mount kit | Yes |
Manual | Yes |
Cooling | |
Cooling type | Active |
Built-in fan | Yes |
Sustainability | |
Sustainability compliance | Yes |
Sustainability certificates | ENERGY STAR |
Weight & dimensions | |
Package width | 560 mm |
Package depth | 620 mm |
Package height | 275 mm |
Weight | 32.3 kg |
Width | 433 mm |
Package weight | 40.3 kg |
Height | 86.5 mm |
Depth | 500 mm |
Packaging data | |
Cables included | Serial, USB cable |
Rack mount kit | Yes |
Manual | Yes |
Package width | 560 mm |
Package depth | 620 mm |
Package height | 275 mm |
Package weight | 40.3 kg |
Logistics data | |
Country of origin | China |
Harmonized System (HS) code | 8504408590 |
Warranty period | 3 year(s) |
Other features | |
Battery type | RBP0129 |
Power | |
---|---|
Output power | 3000 W |
Input operation voltage (min) | 159 V |
Input operation voltage (max) | 288 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 2430 J |
Maximum current | 10 A |
Emergency Power Off (EPO) | Yes |
Power factor | 1 |
Output power capacity | 3 kVA |
Power Factor Correction (PFC) type | Active |
Ports & interfaces | |
Cable length | 2.4 m |
Emergency Power Off (EPO) connector | Yes |
USB port | Yes |
Serial interface | Yes |
Serial interface type | RS-232 |
AC outlets quantity | 8 AC outlet(s) |
AC outlet types | C13 coupler, C19 coupler |
Power plug | C20 coupler |
Serial ports quantity | 1 |
RS-232 ports | 1 |
Ethernet LAN (RJ-45) ports | 2 |
Battery | |
Battery type | RBP0129 |
Number of batteries supported | 1 |
Battery technology | Sealed Lead Acid (VRLA) |
Battery recharge time | 3 h |
Typical backup time at half load | 6.4 min |
Typical backup time at full load | 1.3 min |
Hot-swap battery | Yes |
Performance | |
Audible alarm modes | Alarm when on battery, Fault, Low battery alarm, Overload alarm |
UPS topology | Line-Interactive |
Waveform | Pure sine |
Automatic Voltage Regulation (AVR) | Yes |
Number of output phases | 1 |
Number of input phases | 1 |
Response time | 4 ms |
LED indicators | Fault, Power, Status |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Surge protection features | Network |
Power protection features | Overload |
Noise level | 57.5 dB |
Audible alarm(s) | Yes |
Features | |
Output frequency | 50/60 Hz |
Management protocols | SNMP/HTTP |
Country of origin | China |
Audible alarm modes | Alarm when on battery, Fault, Low battery alarm, Overload alarm |
UPS topology | Line-Interactive |
Waveform | Pure sine |
Automatic Voltage Regulation (AVR) | Yes |
Number of output phases | 1 |
Number of input phases | 1 |
Response time | 4 ms |
Output power | 3000 W |
Input operation voltage (min) | 159 V |
Input operation voltage (max) | 288 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 2430 J |
Maximum current | 10 A |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Surge protection features | Network |
Emergency Power Off (EPO) | Yes |
Power protection features | Overload |
Power factor | 1 |
Noise level | 57.5 dB |
Audible alarm(s) | Yes |
Output power capacity | 3 kVA |
Power Factor Correction (PFC) type | Active |
Input frequency | 50/60 Hz |
Heat dissipation | 120.8 BTU/h |
Design | |
Country of origin | China |
Rack capacity | 2U |
Form factor | Rackmount/Tower |
LED indicators | Fault, Power, Status |
Product colour | Black |
Cooling type | Active |
Cable length | 2.4 m |
Built-in fan | Yes |
Housing material | Metal |
Control type | Buttons |
Display type | LCD |
Operational conditions | |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -15 - 45 °C |
Operating relative humidity (H-H) | 0 - 95% |
Storage relative humidity (H-H) | 0 - 95% |
Operating altitude | 0 - 3000 m |
Non-operating altitude | 0 - 15000 m |
Technical details | |
Output frequency | 50/60 Hz |
Sustainability compliance | Yes |
Sustainability certificates | ENERGY STAR |
Harmonized System (HS) code | 8504408590 |
Warranty period | 3 year(s) |
Compliance certificates | RoHS |
Certificates | |
Compliance certificates | RoHS |
Management features | |
Management protocols | SNMP/HTTP |
Packaging content | |
Cables included | Serial, USB cable |
Rack mount kit | Yes |
Manual | Yes |
Cooling | |
Cooling type | Active |
Built-in fan | Yes |
Sustainability | |
Sustainability compliance | Yes |
Sustainability certificates | ENERGY STAR |
Weight & dimensions | |
Package width | 560 mm |
Package depth | 620 mm |
Package height | 275 mm |
Weight | 32.3 kg |
Width | 433 mm |
Package weight | 40.3 kg |
Height | 86.5 mm |
Depth | 500 mm |
Packaging data | |
Cables included | Serial, USB cable |
Rack mount kit | Yes |
Manual | Yes |
Package width | 560 mm |
Package depth | 620 mm |
Package height | 275 mm |
Package weight | 40.3 kg |
Logistics data | |
Country of origin | China |
Harmonized System (HS) code | 8504408590 |
Warranty period | 3 year(s) |
Other features | |
Battery type | RBP0129 |
Save £438.06
Power | |
---|---|
Output power | 800 W |
Input operation voltage (min) | 150 V |
Input operation voltage (max) | 300 V |
Output operation voltage (min) | 230 V |
Output operation voltage (max) | 230 V |
Surge energy rating | 810 J |
Emergency Power Off (EPO) | Yes |
Power factor | 0.8 |
Output power capacity | 1 kVA |
Performance | |
Audible alarm modes | Alarm when on battery, Fault, Low battery alarm, Overload alarm |
UPS topology | Line-Interactive |
Waveform | Pure sine |
Automatic Voltage Regulation (AVR) | Yes |
Response time | 4 ms |
LED indicators | Operation |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Power protection features | Overload |
Audible alarm(s) | Yes |
Features | |
Output frequency | 50/60 Hz |
Country of origin | China |
Audible alarm modes | Alarm when on battery, Fault, Low battery alarm, Overload alarm |
UPS topology | Line-Interactive |
Waveform | Pure sine |
Automatic Voltage Regulation (AVR) | Yes |
Response time | 4 ms |
Output power | 800 W |
Input operation voltage (min) | 150 V |
Input operation voltage (max) | 300 V |
Output operation voltage (min) | 230 V |
Output operation voltage (max) | 230 V |
Surge energy rating | 810 J |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Emergency Power Off (EPO) | Yes |
Power protection features | Overload |
Power factor | 0.8 |
Audible alarm(s) | Yes |
Output power capacity | 1 kVA |
Input frequency | 50/60 Hz |
Ports & interfaces | |
USB port | Yes |
AC outlets quantity | 6 AC outlet(s) |
AC outlet types | C13 coupler |
Power plug | C14 coupler |
Battery | |
Battery technology | Sealed Lead Acid (VRLA) |
Number of battery cells | 1 |
Battery recharge time | 6 h |
Typical backup time at half load | 12 min |
Typical backup time at full load | 3.1 min |
Hot-swap battery | Yes |
Design | |
Country of origin | China |
Rack capacity | 1U |
Form factor | Rackmount/Tower |
LED indicators | Operation |
Product colour | Black |
Certification | CE, EAC, RCM, RoHS |
Housing material | Metal |
Display type | LCD |
Operational conditions | |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -15 - 45 °C |
Operating relative humidity (H-H) | 0 - 95% |
Storage relative humidity (H-H) | 0 - 95% |
Operating altitude | 0 - 3000 m |
Non-operating altitude | 0 - 15000 m |
Technical details | |
Output frequency | 50/60 Hz |
Harmonized System (HS) code | 8504408590 |
Weight & dimensions | |
Package width | 540 mm |
Package depth | 610 mm |
Package height | 158 mm |
Weight | 18 kg |
Width | 433 mm |
Package weight | 22 kg |
Height | 44 mm |
Depth | 490 mm |
Packaging data | |
Package width | 540 mm |
Package depth | 610 mm |
Package height | 158 mm |
Package weight | 22 kg |
Logistics data | |
Harmonized System (HS) code | 8504408590 |
Certificates | |
Certification | CE, EAC, RCM, RoHS |
Power | |
---|---|
Output power | 800 W |
Input operation voltage (min) | 150 V |
Input operation voltage (max) | 300 V |
Output operation voltage (min) | 230 V |
Output operation voltage (max) | 230 V |
Surge energy rating | 810 J |
Emergency Power Off (EPO) | Yes |
Power factor | 0.8 |
Output power capacity | 1 kVA |
Performance | |
Audible alarm modes | Alarm when on battery, Fault, Low battery alarm, Overload alarm |
UPS topology | Line-Interactive |
Waveform | Pure sine |
Automatic Voltage Regulation (AVR) | Yes |
Response time | 4 ms |
LED indicators | Operation |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Power protection features | Overload |
Audible alarm(s) | Yes |
Features | |
Output frequency | 50/60 Hz |
Country of origin | China |
Audible alarm modes | Alarm when on battery, Fault, Low battery alarm, Overload alarm |
UPS topology | Line-Interactive |
Waveform | Pure sine |
Automatic Voltage Regulation (AVR) | Yes |
Response time | 4 ms |
Output power | 800 W |
Input operation voltage (min) | 150 V |
Input operation voltage (max) | 300 V |
Output operation voltage (min) | 230 V |
Output operation voltage (max) | 230 V |
Surge energy rating | 810 J |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Emergency Power Off (EPO) | Yes |
Power protection features | Overload |
Power factor | 0.8 |
Audible alarm(s) | Yes |
Output power capacity | 1 kVA |
Input frequency | 50/60 Hz |
Ports & interfaces | |
USB port | Yes |
AC outlets quantity | 6 AC outlet(s) |
AC outlet types | C13 coupler |
Power plug | C14 coupler |
Battery | |
Battery technology | Sealed Lead Acid (VRLA) |
Number of battery cells | 1 |
Battery recharge time | 6 h |
Typical backup time at half load | 12 min |
Typical backup time at full load | 3.1 min |
Hot-swap battery | Yes |
Design | |
Country of origin | China |
Rack capacity | 1U |
Form factor | Rackmount/Tower |
LED indicators | Operation |
Product colour | Black |
Certification | CE, EAC, RCM, RoHS |
Housing material | Metal |
Display type | LCD |
Operational conditions | |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -15 - 45 °C |
Operating relative humidity (H-H) | 0 - 95% |
Storage relative humidity (H-H) | 0 - 95% |
Operating altitude | 0 - 3000 m |
Non-operating altitude | 0 - 15000 m |
Technical details | |
Output frequency | 50/60 Hz |
Harmonized System (HS) code | 8504408590 |
Weight & dimensions | |
Package width | 540 mm |
Package depth | 610 mm |
Package height | 158 mm |
Weight | 18 kg |
Width | 433 mm |
Package weight | 22 kg |
Height | 44 mm |
Depth | 490 mm |
Packaging data | |
Package width | 540 mm |
Package depth | 610 mm |
Package height | 158 mm |
Package weight | 22 kg |
Logistics data | |
Harmonized System (HS) code | 8504408590 |
Certificates | |
Certification | CE, EAC, RCM, RoHS |
Save £262.75
Power | |
---|---|
Output power | 750 W |
Input operation voltage (min) | 159 V |
Input operation voltage (max) | 288 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 2430 J |
Maximum current | 10 A |
Power factor | 1 |
Output power capacity | 0.75 kVA |
Power Factor Correction (PFC) type | Active |
Ports & interfaces | |
Cable length | 1.8 m |
Emergency Power Off (EPO) connector | Yes |
USB port | Yes |
Serial interface | Yes |
Serial interface type | RS-232 |
AC outlets quantity | 10 AC outlet(s) |
AC outlet types | C13 coupler |
Power plug | C14 coupler |
USB 2.0 ports quantity | 1 |
Ethernet LAN (RJ-45) ports | 2 |
Performance | |
Audible alarm modes | Alarm when on battery, Low battery alarm, Overload alarm |
UPS topology | Line-Interactive |
Waveform | Pure sine |
Automatic Voltage Regulation (AVR) | Yes |
Number of input phases | 1 |
Response time | 4 ms |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Power protection features | Overload, Short circuit |
Noise level | 52.5 dB |
Audible alarm(s) | Yes |
Features | |
Country of origin | China |
Audible alarm modes | Alarm when on battery, Low battery alarm, Overload alarm |
UPS topology | Line-Interactive |
Waveform | Pure sine |
Automatic Voltage Regulation (AVR) | Yes |
Number of input phases | 1 |
Response time | 4 ms |
Output power | 750 W |
Input operation voltage (min) | 159 V |
Input operation voltage (max) | 288 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 2430 J |
Maximum current | 10 A |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Power protection features | Overload, Short circuit |
Power factor | 1 |
Noise level | 52.5 dB |
Audible alarm(s) | Yes |
Output power capacity | 0.75 kVA |
Power Factor Correction (PFC) type | Active |
Input frequency | 50/60 Hz |
Battery | |
Number of batteries supported | 1 |
Battery technology | Sealed Lead Acid (VRLA) |
Battery recharge time | 3 h |
Typical backup time at half load | 20 min |
Typical backup time at full load | 6.4 min |
Hot-swap battery | Yes |
Replacement battery cartridge | RBP0127 |
Design | |
Country of origin | China |
Rack capacity | 2U |
Form factor | Rackmount/Tower |
Product colour | Black |
Certification | CE , FCC Class B , UL , RCM , VCCI, RoHS |
Cable length | 1.8 m |
Housing material | Metal |
Display type | LCD |
Operational conditions | |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -15 - 45 °C |
Operating relative humidity (H-H) | 0 - 95% |
Storage relative humidity (H-H) | 0 - 95% |
Operating altitude | 0 - 3000 m |
Non-operating altitude | 0 - 15000 m |
Technical details | |
Sustainability certificates | ENERGY STAR |
Harmonized System (HS) code | 8504408590 |
Compliance certificates | RoHS |
Weight & dimensions | |
Package width | 560 mm |
Package depth | 530 mm |
Package height | 275 mm |
Weight | 18.3 kg |
Width | 433 mm |
Package weight | 24.9 kg |
Height | 86.5 mm |
Depth | 412 mm |
Packaging data | |
Cables included | Serial, USB cable |
Rack mount kit | Yes |
Package width | 560 mm |
Package depth | 530 mm |
Package height | 275 mm |
Package weight | 24.9 kg |
Logistics data | |
Harmonized System (HS) code | 8504408590 |
Certificates | |
Certification | CE , FCC Class B , UL , RCM , VCCI, RoHS |
Packaging content | |
Cables included | Serial, USB cable |
Rack mount kit | Yes |
Power | |
---|---|
Output power | 750 W |
Input operation voltage (min) | 159 V |
Input operation voltage (max) | 288 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 2430 J |
Maximum current | 10 A |
Power factor | 1 |
Output power capacity | 0.75 kVA |
Power Factor Correction (PFC) type | Active |
Ports & interfaces | |
Cable length | 1.8 m |
Emergency Power Off (EPO) connector | Yes |
USB port | Yes |
Serial interface | Yes |
Serial interface type | RS-232 |
AC outlets quantity | 10 AC outlet(s) |
AC outlet types | C13 coupler |
Power plug | C14 coupler |
USB 2.0 ports quantity | 1 |
Ethernet LAN (RJ-45) ports | 2 |
Performance | |
Audible alarm modes | Alarm when on battery, Low battery alarm, Overload alarm |
UPS topology | Line-Interactive |
Waveform | Pure sine |
Automatic Voltage Regulation (AVR) | Yes |
Number of input phases | 1 |
Response time | 4 ms |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Power protection features | Overload, Short circuit |
Noise level | 52.5 dB |
Audible alarm(s) | Yes |
Features | |
Country of origin | China |
Audible alarm modes | Alarm when on battery, Low battery alarm, Overload alarm |
UPS topology | Line-Interactive |
Waveform | Pure sine |
Automatic Voltage Regulation (AVR) | Yes |
Number of input phases | 1 |
Response time | 4 ms |
Output power | 750 W |
Input operation voltage (min) | 159 V |
Input operation voltage (max) | 288 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 2430 J |
Maximum current | 10 A |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Power protection features | Overload, Short circuit |
Power factor | 1 |
Noise level | 52.5 dB |
Audible alarm(s) | Yes |
Output power capacity | 0.75 kVA |
Power Factor Correction (PFC) type | Active |
Input frequency | 50/60 Hz |
Battery | |
Number of batteries supported | 1 |
Battery technology | Sealed Lead Acid (VRLA) |
Battery recharge time | 3 h |
Typical backup time at half load | 20 min |
Typical backup time at full load | 6.4 min |
Hot-swap battery | Yes |
Replacement battery cartridge | RBP0127 |
Design | |
Country of origin | China |
Rack capacity | 2U |
Form factor | Rackmount/Tower |
Product colour | Black |
Certification | CE , FCC Class B , UL , RCM , VCCI, RoHS |
Cable length | 1.8 m |
Housing material | Metal |
Display type | LCD |
Operational conditions | |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -15 - 45 °C |
Operating relative humidity (H-H) | 0 - 95% |
Storage relative humidity (H-H) | 0 - 95% |
Operating altitude | 0 - 3000 m |
Non-operating altitude | 0 - 15000 m |
Technical details | |
Sustainability certificates | ENERGY STAR |
Harmonized System (HS) code | 8504408590 |
Compliance certificates | RoHS |
Weight & dimensions | |
Package width | 560 mm |
Package depth | 530 mm |
Package height | 275 mm |
Weight | 18.3 kg |
Width | 433 mm |
Package weight | 24.9 kg |
Height | 86.5 mm |
Depth | 412 mm |
Packaging data | |
Cables included | Serial, USB cable |
Rack mount kit | Yes |
Package width | 560 mm |
Package depth | 530 mm |
Package height | 275 mm |
Package weight | 24.9 kg |
Logistics data | |
Harmonized System (HS) code | 8504408590 |
Certificates | |
Certification | CE , FCC Class B , UL , RCM , VCCI, RoHS |
Packaging content | |
Cables included | Serial, USB cable |
Rack mount kit | Yes |
Save £464.72
Power | |
---|---|
Output power factor | 1 |
Output power | 3000 W |
Input operation voltage (min) | 159 V |
Input operation voltage (max) | 288 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 2430 J |
Maximum current | 16 A |
Emergency Power Off (EPO) | Yes |
Output power capacity | 3 kVA |
Power Factor Correction (PFC) type | Active |
Ports & interfaces | |
Cable length | 2.4 m |
Emergency Power Off (EPO) connector | Yes |
USB port | Yes |
Serial interface | Yes |
Serial interface type | RS-232 |
AC outlets quantity | 10 AC outlet(s) |
AC outlet types | C13 coupler, C19 coupler |
Power plug | C20 coupler |
USB 2.0 ports quantity | 1 |
Serial ports quantity | 2 |
RS-232 ports | 2 |
Ethernet LAN (RJ-45) ports | 3 |
USB port type | USB Type-B |
Battery | |
Battery type | RBP0130 |
Number of batteries supported | 1 |
Battery technology | Sealed Lead Acid (VRLA) |
Battery recharge time | 3 h |
Typical backup time at half load | 11.2 min |
Typical backup time at full load | 3.8 min |
Hot-swap battery | Yes |
Performance | |
Audible alarm modes | Alarm when on battery, Fault, Low battery alarm, Overload alarm |
UPS topology | Line-Interactive |
Waveform | Pure sine |
Automatic Voltage Regulation (AVR) | Yes |
Number of output phases | 1 |
Number of input phases | 1 |
Response time | 6 ms |
LED indicators | Yes |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Power protection features | Overload |
Features | |
Output frequency | 50/60 Hz |
Country of origin | China |
Audible alarm modes | Alarm when on battery, Fault, Low battery alarm, Overload alarm |
UPS topology | Line-Interactive |
Waveform | Pure sine |
Automatic Voltage Regulation (AVR) | Yes |
Number of output phases | 1 |
Number of input phases | 1 |
Output power factor | 1 |
Response time | 6 ms |
Output power | 3000 W |
Input operation voltage (min) | 159 V |
Input operation voltage (max) | 288 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 2430 J |
Maximum current | 16 A |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Emergency Power Off (EPO) | Yes |
Power protection features | Overload |
Output power capacity | 3 kVA |
Power Factor Correction (PFC) type | Active |
Input frequency | 50/60 Hz |
Power source type | AC |
Detachable power cord | Yes |
Heat dissipation | 120.8 BTU/h |
Package type | Box |
Design | |
Country of origin | China |
Rack capacity | 2U |
Form factor | Rackmount/Tower |
LED indicators | Yes |
Product colour | Black |
Cooling type | Active |
Cable length | 2.4 m |
Built-in fan | Yes |
Housing material | Metal |
Control type | Buttons |
Display type | LCD |
Extended battery module rack capacity | 2U |
Operational conditions | |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -15 - 45 °C |
Operating relative humidity (H-H) | 0 - 95% |
Storage relative humidity (H-H) | 0 - 95% |
Operating altitude | 0 - 3000 m |
Non-operating altitude | 0 - 15000 m |
Technical details | |
Output frequency | 50/60 Hz |
Sustainability compliance | Yes |
Compliance certificates | CE, Federal Communications Commission (FCC), RCM, RoHS, UL, VCCI |
Packaging content | |
Batteries included | Yes |
Cables included | Serial |
Rack mount kit | Yes |
Manual | Yes |
Cooling | |
Cooling type | Active |
Built-in fan | Yes |
Weight & dimensions | |
Package type | Box |
Package width | 575 mm |
Package depth | 765 mm |
Package height | 275 mm |
Weight | 38.9 kg |
Width | 433 mm |
Package weight | 48.1 kg |
Height | 86.5 mm |
Depth | 630 mm |
Packaging data | |
Cables included | Serial |
Rack mount kit | Yes |
Manual | Yes |
Package type | Box |
Package width | 575 mm |
Package depth | 765 mm |
Package height | 275 mm |
Package weight | 48.1 kg |
Other features | |
Battery type | RBP0130 |
Power | |
---|---|
Output power factor | 1 |
Output power | 3000 W |
Input operation voltage (min) | 159 V |
Input operation voltage (max) | 288 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 2430 J |
Maximum current | 16 A |
Emergency Power Off (EPO) | Yes |
Output power capacity | 3 kVA |
Power Factor Correction (PFC) type | Active |
Ports & interfaces | |
Cable length | 2.4 m |
Emergency Power Off (EPO) connector | Yes |
USB port | Yes |
Serial interface | Yes |
Serial interface type | RS-232 |
AC outlets quantity | 10 AC outlet(s) |
AC outlet types | C13 coupler, C19 coupler |
Power plug | C20 coupler |
USB 2.0 ports quantity | 1 |
Serial ports quantity | 2 |
RS-232 ports | 2 |
Ethernet LAN (RJ-45) ports | 3 |
USB port type | USB Type-B |
Battery | |
Battery type | RBP0130 |
Number of batteries supported | 1 |
Battery technology | Sealed Lead Acid (VRLA) |
Battery recharge time | 3 h |
Typical backup time at half load | 11.2 min |
Typical backup time at full load | 3.8 min |
Hot-swap battery | Yes |
Performance | |
Audible alarm modes | Alarm when on battery, Fault, Low battery alarm, Overload alarm |
UPS topology | Line-Interactive |
Waveform | Pure sine |
Automatic Voltage Regulation (AVR) | Yes |
Number of output phases | 1 |
Number of input phases | 1 |
Response time | 6 ms |
LED indicators | Yes |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Power protection features | Overload |
Features | |
Output frequency | 50/60 Hz |
Country of origin | China |
Audible alarm modes | Alarm when on battery, Fault, Low battery alarm, Overload alarm |
UPS topology | Line-Interactive |
Waveform | Pure sine |
Automatic Voltage Regulation (AVR) | Yes |
Number of output phases | 1 |
Number of input phases | 1 |
Output power factor | 1 |
Response time | 6 ms |
Output power | 3000 W |
Input operation voltage (min) | 159 V |
Input operation voltage (max) | 288 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 2430 J |
Maximum current | 16 A |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Emergency Power Off (EPO) | Yes |
Power protection features | Overload |
Output power capacity | 3 kVA |
Power Factor Correction (PFC) type | Active |
Input frequency | 50/60 Hz |
Power source type | AC |
Detachable power cord | Yes |
Heat dissipation | 120.8 BTU/h |
Package type | Box |
Design | |
Country of origin | China |
Rack capacity | 2U |
Form factor | Rackmount/Tower |
LED indicators | Yes |
Product colour | Black |
Cooling type | Active |
Cable length | 2.4 m |
Built-in fan | Yes |
Housing material | Metal |
Control type | Buttons |
Display type | LCD |
Extended battery module rack capacity | 2U |
Operational conditions | |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -15 - 45 °C |
Operating relative humidity (H-H) | 0 - 95% |
Storage relative humidity (H-H) | 0 - 95% |
Operating altitude | 0 - 3000 m |
Non-operating altitude | 0 - 15000 m |
Technical details | |
Output frequency | 50/60 Hz |
Sustainability compliance | Yes |
Compliance certificates | CE, Federal Communications Commission (FCC), RCM, RoHS, UL, VCCI |
Packaging content | |
Batteries included | Yes |
Cables included | Serial |
Rack mount kit | Yes |
Manual | Yes |
Cooling | |
Cooling type | Active |
Built-in fan | Yes |
Weight & dimensions | |
Package type | Box |
Package width | 575 mm |
Package depth | 765 mm |
Package height | 275 mm |
Weight | 38.9 kg |
Width | 433 mm |
Package weight | 48.1 kg |
Height | 86.5 mm |
Depth | 630 mm |
Packaging data | |
Cables included | Serial |
Rack mount kit | Yes |
Manual | Yes |
Package type | Box |
Package width | 575 mm |
Package depth | 765 mm |
Package height | 275 mm |
Package weight | 48.1 kg |
Other features | |
Battery type | RBP0130 |
Save £743.44
Power | |
---|---|
Output power factor | 1 |
Output power | 1500 W |
Input operation voltage (min) | 148 V |
Input operation voltage (max) | 288 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 2430 J |
Maximum current | 16 A |
Emergency Power Off (EPO) | Yes |
Output power capacity | 1.5 kVA |
Power Factor Correction (PFC) type | Active |
Ports & interfaces | |
Cable length | 3.05 m |
Emergency Power Off (EPO) connector | Yes |
USB port | Yes |
Serial interface | Yes |
Serial interface type | RS-232 |
AC outlets quantity | 10 AC outlet(s) |
AC outlet types | C13 coupler |
Power plug | C14 coupler |
USB 2.0 ports quantity | 1 |
Serial ports quantity | 2 |
RS-232 ports | 2 |
Ethernet LAN (RJ-45) ports | 2 |
USB port type | USB Type-B |
Battery | |
Battery type | RBP0128 |
Number of batteries supported | 1 |
Battery technology | Sealed Lead Acid (VRLA) |
Battery recharge time | 3 h |
Typical backup time at half load | 19.3 min |
Typical backup time at full load | 6.5 min |
Hot-swap battery | Yes |
Performance | |
Audible alarm modes | Alarm when on battery, Fault, Low battery alarm, Overload alarm |
UPS topology | Line-Interactive |
Waveform | Pure sine |
Automatic Voltage Regulation (AVR) | Yes |
Number of output phases | 1 |
Number of input phases | 1 |
Response time | 6 ms |
LED indicators | Yes |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Power protection features | Overload |
Features | |
Output frequency | 50/60 Hz |
Country of origin | China |
Audible alarm modes | Alarm when on battery, Fault, Low battery alarm, Overload alarm |
UPS topology | Line-Interactive |
Waveform | Pure sine |
Automatic Voltage Regulation (AVR) | Yes |
Number of output phases | 1 |
Number of input phases | 1 |
Output power factor | 1 |
Response time | 6 ms |
Output power | 1500 W |
Input operation voltage (min) | 148 V |
Input operation voltage (max) | 288 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 2430 J |
Maximum current | 16 A |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Emergency Power Off (EPO) | Yes |
Power protection features | Overload |
Output power capacity | 1.5 kVA |
Power Factor Correction (PFC) type | Active |
Input frequency | 50/60 Hz |
Power source type | AC |
Detachable power cord | Yes |
Heat dissipation | 96.7 BTU/h |
Package type | Box |
Design | |
Country of origin | China |
Rack capacity | 2U |
Form factor | Rackmount/Tower |
LED indicators | Yes |
Product colour | Black |
Cooling type | Active |
Cable length | 3.05 m |
Built-in fan | Yes |
Housing material | Metal |
Control type | Buttons |
Display type | LCD |
Extended battery module rack capacity | 2U |
Operational conditions | |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -15 - 45 °C |
Operating relative humidity (H-H) | 0 - 95% |
Storage relative humidity (H-H) | 0 - 95% |
Operating altitude | 0 - 3000 m |
Non-operating altitude | 0 - 15000 m |
Technical details | |
Output frequency | 50/60 Hz |
Sustainability compliance | Yes |
Compliance certificates | CE, Federal Communications Commission (FCC), RCM, RoHS, UL, VCCI |
Packaging content | |
Batteries included | Yes |
Cables included | Serial |
Rack mount kit | Yes |
Manual | Yes |
Cooling | |
Cooling type | Active |
Built-in fan | Yes |
Weight & dimensions | |
Package type | Box |
Package width | 560 mm |
Package depth | 620 mm |
Package height | 275 mm |
Weight | 32 kg |
Width | 433 mm |
Package weight | 38.8 kg |
Height | 86.5 mm |
Depth | 500 mm |
Packaging data | |
Cables included | Serial |
Rack mount kit | Yes |
Manual | Yes |
Package type | Box |
Package width | 560 mm |
Package depth | 620 mm |
Package height | 275 mm |
Package weight | 38.8 kg |
Other features | |
Battery type | RBP0128 |
Power | |
---|---|
Output power factor | 1 |
Output power | 1500 W |
Input operation voltage (min) | 148 V |
Input operation voltage (max) | 288 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 2430 J |
Maximum current | 16 A |
Emergency Power Off (EPO) | Yes |
Output power capacity | 1.5 kVA |
Power Factor Correction (PFC) type | Active |
Ports & interfaces | |
Cable length | 3.05 m |
Emergency Power Off (EPO) connector | Yes |
USB port | Yes |
Serial interface | Yes |
Serial interface type | RS-232 |
AC outlets quantity | 10 AC outlet(s) |
AC outlet types | C13 coupler |
Power plug | C14 coupler |
USB 2.0 ports quantity | 1 |
Serial ports quantity | 2 |
RS-232 ports | 2 |
Ethernet LAN (RJ-45) ports | 2 |
USB port type | USB Type-B |
Battery | |
Battery type | RBP0128 |
Number of batteries supported | 1 |
Battery technology | Sealed Lead Acid (VRLA) |
Battery recharge time | 3 h |
Typical backup time at half load | 19.3 min |
Typical backup time at full load | 6.5 min |
Hot-swap battery | Yes |
Performance | |
Audible alarm modes | Alarm when on battery, Fault, Low battery alarm, Overload alarm |
UPS topology | Line-Interactive |
Waveform | Pure sine |
Automatic Voltage Regulation (AVR) | Yes |
Number of output phases | 1 |
Number of input phases | 1 |
Response time | 6 ms |
LED indicators | Yes |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Power protection features | Overload |
Features | |
Output frequency | 50/60 Hz |
Country of origin | China |
Audible alarm modes | Alarm when on battery, Fault, Low battery alarm, Overload alarm |
UPS topology | Line-Interactive |
Waveform | Pure sine |
Automatic Voltage Regulation (AVR) | Yes |
Number of output phases | 1 |
Number of input phases | 1 |
Output power factor | 1 |
Response time | 6 ms |
Output power | 1500 W |
Input operation voltage (min) | 148 V |
Input operation voltage (max) | 288 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 2430 J |
Maximum current | 16 A |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Emergency Power Off (EPO) | Yes |
Power protection features | Overload |
Output power capacity | 1.5 kVA |
Power Factor Correction (PFC) type | Active |
Input frequency | 50/60 Hz |
Power source type | AC |
Detachable power cord | Yes |
Heat dissipation | 96.7 BTU/h |
Package type | Box |
Design | |
Country of origin | China |
Rack capacity | 2U |
Form factor | Rackmount/Tower |
LED indicators | Yes |
Product colour | Black |
Cooling type | Active |
Cable length | 3.05 m |
Built-in fan | Yes |
Housing material | Metal |
Control type | Buttons |
Display type | LCD |
Extended battery module rack capacity | 2U |
Operational conditions | |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -15 - 45 °C |
Operating relative humidity (H-H) | 0 - 95% |
Storage relative humidity (H-H) | 0 - 95% |
Operating altitude | 0 - 3000 m |
Non-operating altitude | 0 - 15000 m |
Technical details | |
Output frequency | 50/60 Hz |
Sustainability compliance | Yes |
Compliance certificates | CE, Federal Communications Commission (FCC), RCM, RoHS, UL, VCCI |
Packaging content | |
Batteries included | Yes |
Cables included | Serial |
Rack mount kit | Yes |
Manual | Yes |
Cooling | |
Cooling type | Active |
Built-in fan | Yes |
Weight & dimensions | |
Package type | Box |
Package width | 560 mm |
Package depth | 620 mm |
Package height | 275 mm |
Weight | 32 kg |
Width | 433 mm |
Package weight | 38.8 kg |
Height | 86.5 mm |
Depth | 500 mm |
Packaging data | |
Cables included | Serial |
Rack mount kit | Yes |
Manual | Yes |
Package type | Box |
Package width | 560 mm |
Package depth | 620 mm |
Package height | 275 mm |
Package weight | 38.8 kg |
Other features | |
Battery type | RBP0128 |
Save £642.60
Power | |
---|---|
Output power factor | 1 |
Output power | 1000 W |
Input operation voltage (min) | 148 V |
Input operation voltage (max) | 288 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 2430 J |
Maximum current | 16 A |
Emergency Power Off (EPO) | Yes |
Output power capacity | 1 kVA |
Power Factor Correction (PFC) type | Active |
Ports & interfaces | |
Cable length | 3.05 m |
Emergency Power Off (EPO) connector | Yes |
USB port | Yes |
Serial interface | Yes |
Serial interface type | RS-232 |
AC outlets quantity | 10 AC outlet(s) |
AC outlet types | C13 coupler |
Power plug | C14 coupler |
USB 2.0 ports quantity | 1 |
Serial ports quantity | 2 |
RS-232 ports | 2 |
Ethernet LAN (RJ-45) ports | 2 |
USB port type | USB Type-B |
Battery | |
Battery type | RBP0128 |
Number of batteries supported | 1 |
Battery technology | Sealed Lead Acid (VRLA) |
Battery recharge time | 3 h |
Typical backup time at half load | 21.3 min |
Typical backup time at full load | 7.9 min |
Hot-swap battery | Yes |
Performance | |
Audible alarm modes | Alarm when on battery, Fault, Low battery alarm, Overload alarm |
UPS topology | Line-Interactive |
Waveform | Pure sine |
Automatic Voltage Regulation (AVR) | Yes |
Number of output phases | 1 |
Number of input phases | 1 |
Response time | 6 ms |
LED indicators | Yes |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Power protection features | Overload |
Features | |
Output frequency | 50/60 Hz |
Country of origin | China |
Audible alarm modes | Alarm when on battery, Fault, Low battery alarm, Overload alarm |
UPS topology | Line-Interactive |
Waveform | Pure sine |
Automatic Voltage Regulation (AVR) | Yes |
Number of output phases | 1 |
Number of input phases | 1 |
Output power factor | 1 |
Response time | 6 ms |
Output power | 1000 W |
Input operation voltage (min) | 148 V |
Input operation voltage (max) | 288 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 2430 J |
Maximum current | 16 A |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Emergency Power Off (EPO) | Yes |
Power protection features | Overload |
Output power capacity | 1 kVA |
Power Factor Correction (PFC) type | Active |
Input frequency | 50/60 Hz |
Power source type | AC |
Detachable power cord | Yes |
Heat dissipation | 49.5 BTU/h |
Package type | Box |
Design | |
Country of origin | China |
Rack capacity | 2U |
Form factor | Rackmount/Tower |
LED indicators | Yes |
Product colour | Black |
Cooling type | Active |
Cable length | 3.05 m |
Built-in fan | Yes |
Housing material | Metal |
Control type | Buttons |
Display type | LCD |
Extended battery module rack capacity | 2U |
Operational conditions | |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -15 - 45 °C |
Operating relative humidity (H-H) | 0 - 95% |
Storage relative humidity (H-H) | 0 - 95% |
Operating altitude | 0 - 3000 m |
Non-operating altitude | 0 - 15000 m |
Technical details | |
Output frequency | 50/60 Hz |
Sustainability compliance | Yes |
Compliance certificates | CE, Federal Communications Commission (FCC), RCM, RoHS, UL, VCCI |
Packaging content | |
Batteries included | Yes |
Cables included | Serial |
Rack mount kit | Yes |
Manual | Yes |
Cooling | |
Cooling type | Active |
Built-in fan | Yes |
Weight & dimensions | |
Package type | Box |
Package width | 560 mm |
Package depth | 530 mm |
Package height | 275 mm |
Weight | 23.6 kg |
Width | 433 mm |
Package weight | 30.2 kg |
Height | 86.5 mm |
Depth | 412 mm |
Packaging data | |
Cables included | Serial |
Rack mount kit | Yes |
Manual | Yes |
Package type | Box |
Package width | 560 mm |
Package depth | 530 mm |
Package height | 275 mm |
Package weight | 30.2 kg |
Other features | |
Battery type | RBP0128 |
Power | |
---|---|
Output power factor | 1 |
Output power | 1000 W |
Input operation voltage (min) | 148 V |
Input operation voltage (max) | 288 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 2430 J |
Maximum current | 16 A |
Emergency Power Off (EPO) | Yes |
Output power capacity | 1 kVA |
Power Factor Correction (PFC) type | Active |
Ports & interfaces | |
Cable length | 3.05 m |
Emergency Power Off (EPO) connector | Yes |
USB port | Yes |
Serial interface | Yes |
Serial interface type | RS-232 |
AC outlets quantity | 10 AC outlet(s) |
AC outlet types | C13 coupler |
Power plug | C14 coupler |
USB 2.0 ports quantity | 1 |
Serial ports quantity | 2 |
RS-232 ports | 2 |
Ethernet LAN (RJ-45) ports | 2 |
USB port type | USB Type-B |
Battery | |
Battery type | RBP0128 |
Number of batteries supported | 1 |
Battery technology | Sealed Lead Acid (VRLA) |
Battery recharge time | 3 h |
Typical backup time at half load | 21.3 min |
Typical backup time at full load | 7.9 min |
Hot-swap battery | Yes |
Performance | |
Audible alarm modes | Alarm when on battery, Fault, Low battery alarm, Overload alarm |
UPS topology | Line-Interactive |
Waveform | Pure sine |
Automatic Voltage Regulation (AVR) | Yes |
Number of output phases | 1 |
Number of input phases | 1 |
Response time | 6 ms |
LED indicators | Yes |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Power protection features | Overload |
Features | |
Output frequency | 50/60 Hz |
Country of origin | China |
Audible alarm modes | Alarm when on battery, Fault, Low battery alarm, Overload alarm |
UPS topology | Line-Interactive |
Waveform | Pure sine |
Automatic Voltage Regulation (AVR) | Yes |
Number of output phases | 1 |
Number of input phases | 1 |
Output power factor | 1 |
Response time | 6 ms |
Output power | 1000 W |
Input operation voltage (min) | 148 V |
Input operation voltage (max) | 288 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 2430 J |
Maximum current | 16 A |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Emergency Power Off (EPO) | Yes |
Power protection features | Overload |
Output power capacity | 1 kVA |
Power Factor Correction (PFC) type | Active |
Input frequency | 50/60 Hz |
Power source type | AC |
Detachable power cord | Yes |
Heat dissipation | 49.5 BTU/h |
Package type | Box |
Design | |
Country of origin | China |
Rack capacity | 2U |
Form factor | Rackmount/Tower |
LED indicators | Yes |
Product colour | Black |
Cooling type | Active |
Cable length | 3.05 m |
Built-in fan | Yes |
Housing material | Metal |
Control type | Buttons |
Display type | LCD |
Extended battery module rack capacity | 2U |
Operational conditions | |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -15 - 45 °C |
Operating relative humidity (H-H) | 0 - 95% |
Storage relative humidity (H-H) | 0 - 95% |
Operating altitude | 0 - 3000 m |
Non-operating altitude | 0 - 15000 m |
Technical details | |
Output frequency | 50/60 Hz |
Sustainability compliance | Yes |
Compliance certificates | CE, Federal Communications Commission (FCC), RCM, RoHS, UL, VCCI |
Packaging content | |
Batteries included | Yes |
Cables included | Serial |
Rack mount kit | Yes |
Manual | Yes |
Cooling | |
Cooling type | Active |
Built-in fan | Yes |
Weight & dimensions | |
Package type | Box |
Package width | 560 mm |
Package depth | 530 mm |
Package height | 275 mm |
Weight | 23.6 kg |
Width | 433 mm |
Package weight | 30.2 kg |
Height | 86.5 mm |
Depth | 412 mm |
Packaging data | |
Cables included | Serial |
Rack mount kit | Yes |
Manual | Yes |
Package type | Box |
Package width | 560 mm |
Package depth | 530 mm |
Package height | 275 mm |
Package weight | 30.2 kg |
Other features | |
Battery type | RBP0128 |
Save £403.87
Power | |
---|---|
Output power factor | 1 |
Output power | 2200 W |
Input operation voltage (min) | 148 V |
Input operation voltage (max) | 288 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 2430 J |
Maximum current | 16 A |
Emergency Power Off (EPO) | Yes |
Output power capacity | 2.2 kVA |
Power Factor Correction (PFC) type | Active |
Ports & interfaces | |
Cable length | 3.05 m |
Emergency Power Off (EPO) connector | Yes |
USB port | Yes |
Serial interface | Yes |
Serial interface type | RS-232 |
AC outlets quantity | 8 AC outlet(s) |
AC outlet types | C13 coupler, C19 coupler |
Power plug | C20 coupler |
USB 2.0 ports quantity | 1 |
Serial ports quantity | 2 |
RS-232 ports | 2 |
Ethernet LAN (RJ-45) ports | 2 |
USB port type | USB Type-B |
Battery | |
Battery type | RBP0129 |
Number of batteries supported | 1 |
Battery technology | Sealed Lead Acid (VRLA) |
Battery recharge time | 3 h |
Typical backup time at half load | 11.2 min |
Typical backup time at full load | 3.2 min |
Hot-swap battery | Yes |
Performance | |
Audible alarm modes | Alarm when on battery, Fault, Low battery alarm, Overload alarm |
UPS topology | Line-Interactive |
Waveform | Pure sine |
Automatic Voltage Regulation (AVR) | Yes |
Number of output phases | 1 |
Number of input phases | 1 |
Response time | 6 ms |
LED indicators | Yes |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Power protection features | Overload |
Features | |
Output frequency | 50/60 Hz |
Country of origin | China |
Audible alarm modes | Alarm when on battery, Fault, Low battery alarm, Overload alarm |
UPS topology | Line-Interactive |
Waveform | Pure sine |
Automatic Voltage Regulation (AVR) | Yes |
Number of output phases | 1 |
Number of input phases | 1 |
Output power factor | 1 |
Response time | 6 ms |
Output power | 2200 W |
Input operation voltage (min) | 148 V |
Input operation voltage (max) | 288 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 2430 J |
Maximum current | 16 A |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Emergency Power Off (EPO) | Yes |
Power protection features | Overload |
Output power capacity | 2.2 kVA |
Power Factor Correction (PFC) type | Active |
Input frequency | 50/60 Hz |
Power source type | AC |
Detachable power cord | Yes |
Heat dissipation | 156.6 BTU/h |
Package type | Box |
Design | |
Country of origin | China |
Rack capacity | 2U |
Form factor | Rackmount/Tower |
LED indicators | Yes |
Product colour | Black |
Cooling type | Active |
Cable length | 3.05 m |
Built-in fan | Yes |
Housing material | Metal |
Control type | Buttons |
Display type | LCD |
Extended battery module rack capacity | 2U |
Operational conditions | |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -15 - 45 °C |
Operating relative humidity (H-H) | 0 - 95% |
Storage relative humidity (H-H) | 0 - 95% |
Operating altitude | 0 - 3000 m |
Non-operating altitude | 0 - 15000 m |
Technical details | |
Output frequency | 50/60 Hz |
Sustainability compliance | Yes |
Compliance certificates | CE, Federal Communications Commission (FCC), RCM, RoHS, UL, VCCI |
Packaging content | |
Batteries included | Yes |
Cables included | Serial |
Rack mount kit | Yes |
Manual | Yes |
Cooling | |
Cooling type | Active |
Built-in fan | Yes |
Weight & dimensions | |
Package type | Box |
Package width | 560 mm |
Package depth | 620 mm |
Package height | 275 mm |
Weight | 34.4 kg |
Width | 433 mm |
Package weight | 42.4 kg |
Height | 86.5 mm |
Depth | 500 mm |
Packaging data | |
Cables included | Serial |
Rack mount kit | Yes |
Manual | Yes |
Package type | Box |
Package width | 560 mm |
Package depth | 620 mm |
Package height | 275 mm |
Package weight | 42.4 kg |
Other features | |
Battery type | RBP0129 |
Power | |
---|---|
Output power factor | 1 |
Output power | 2200 W |
Input operation voltage (min) | 148 V |
Input operation voltage (max) | 288 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 2430 J |
Maximum current | 16 A |
Emergency Power Off (EPO) | Yes |
Output power capacity | 2.2 kVA |
Power Factor Correction (PFC) type | Active |
Ports & interfaces | |
Cable length | 3.05 m |
Emergency Power Off (EPO) connector | Yes |
USB port | Yes |
Serial interface | Yes |
Serial interface type | RS-232 |
AC outlets quantity | 8 AC outlet(s) |
AC outlet types | C13 coupler, C19 coupler |
Power plug | C20 coupler |
USB 2.0 ports quantity | 1 |
Serial ports quantity | 2 |
RS-232 ports | 2 |
Ethernet LAN (RJ-45) ports | 2 |
USB port type | USB Type-B |
Battery | |
Battery type | RBP0129 |
Number of batteries supported | 1 |
Battery technology | Sealed Lead Acid (VRLA) |
Battery recharge time | 3 h |
Typical backup time at half load | 11.2 min |
Typical backup time at full load | 3.2 min |
Hot-swap battery | Yes |
Performance | |
Audible alarm modes | Alarm when on battery, Fault, Low battery alarm, Overload alarm |
UPS topology | Line-Interactive |
Waveform | Pure sine |
Automatic Voltage Regulation (AVR) | Yes |
Number of output phases | 1 |
Number of input phases | 1 |
Response time | 6 ms |
LED indicators | Yes |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Power protection features | Overload |
Features | |
Output frequency | 50/60 Hz |
Country of origin | China |
Audible alarm modes | Alarm when on battery, Fault, Low battery alarm, Overload alarm |
UPS topology | Line-Interactive |
Waveform | Pure sine |
Automatic Voltage Regulation (AVR) | Yes |
Number of output phases | 1 |
Number of input phases | 1 |
Output power factor | 1 |
Response time | 6 ms |
Output power | 2200 W |
Input operation voltage (min) | 148 V |
Input operation voltage (max) | 288 V |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 2430 J |
Maximum current | 16 A |
EMI/RFI noise filtering | Yes |
Surge protection | Yes |
Emergency Power Off (EPO) | Yes |
Power protection features | Overload |
Output power capacity | 2.2 kVA |
Power Factor Correction (PFC) type | Active |
Input frequency | 50/60 Hz |
Power source type | AC |
Detachable power cord | Yes |
Heat dissipation | 156.6 BTU/h |
Package type | Box |
Design | |
Country of origin | China |
Rack capacity | 2U |
Form factor | Rackmount/Tower |
LED indicators | Yes |
Product colour | Black |
Cooling type | Active |
Cable length | 3.05 m |
Built-in fan | Yes |
Housing material | Metal |
Control type | Buttons |
Display type | LCD |
Extended battery module rack capacity | 2U |
Operational conditions | |
Operating temperature (T-T) | 0 - 40 °C |
Storage temperature (T-T) | -15 - 45 °C |
Operating relative humidity (H-H) | 0 - 95% |
Storage relative humidity (H-H) | 0 - 95% |
Operating altitude | 0 - 3000 m |
Non-operating altitude | 0 - 15000 m |
Technical details | |
Output frequency | 50/60 Hz |
Sustainability compliance | Yes |
Compliance certificates | CE, Federal Communications Commission (FCC), RCM, RoHS, UL, VCCI |
Packaging content | |
Batteries included | Yes |
Cables included | Serial |
Rack mount kit | Yes |
Manual | Yes |
Cooling | |
Cooling type | Active |
Built-in fan | Yes |
Weight & dimensions | |
Package type | Box |
Package width | 560 mm |
Package depth | 620 mm |
Package height | 275 mm |
Weight | 34.4 kg |
Width | 433 mm |
Package weight | 42.4 kg |
Height | 86.5 mm |
Depth | 500 mm |
Packaging data | |
Cables included | Serial |
Rack mount kit | Yes |
Manual | Yes |
Package type | Box |
Package width | 560 mm |
Package depth | 620 mm |
Package height | 275 mm |
Package weight | 42.4 kg |
Other features | |
Battery type | RBP0129 |
Save £720.87
Save £6.18
