| Performance |
|---|
| Copper ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
| Ethernet LAN interface type | Gigabit Ethernet |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Wi-Fi standards | 802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Ethernet LAN | Yes |
| WLAN data transfer rates supported | 300,867 Mbit/s |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Wi-Fi | Yes |
| Maximum data transfer rate | 1200 Mbit/s |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x |
| Built-in power socket | Yes |
| Modulation | 64-QAM, 256-QAM, 1024-QAM, 4096-QAM, BPSK, DSSS, OFDM, QPSK |
| Security algorithms | 128-bit AES, WPA, WPA2, WPS-PBC, WPS-PIN |
| Maximum operating distance | 400 m |
| Encryption button | Yes |
| Filter characteristics | -22 - -45 dB |
| Damping filter | 2 - 80 MHz |
| Quality of Service (QoS) support | Yes |
| Compatible products | devolo Magic |
| MIMO | Yes |
| Technical details |
|---|
| Copper ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
| Antenna type | Internal |
| Ethernet LAN interface type | Gigabit Ethernet |
| Top Wi-Fi standard | Wi-Fi 5 (802.11ac) |
| Wi-Fi standards | 802.11a, Wi-Fi 5 (802.11ac), 802.11b, 802.11g, Wi-Fi 4 (802.11n) |
| Ethernet LAN | Yes |
| WLAN data transfer rates supported | 300,867 Mbit/s |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Wi-Fi | Yes |
| Maximum data transfer rate | 1200 Mbit/s |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x |
| Built-in power socket | Yes |
| Modulation | 64-QAM, 256-QAM, 1024-QAM, 4096-QAM, BPSK, DSSS, OFDM, QPSK |
| Security algorithms | 128-bit AES, WPA, WPA2, WPS-PBC, WPS-PIN |
| Maximum operating distance | 400 m |
| LED indicators | Yes |
| Encryption button | Yes |
| Product colour | White |
| Filter characteristics | -22 - -45 dB |
| Damping filter | 2 - 80 MHz |
| Quality of Service (QoS) support | Yes |
| Certification | CE |
| Compatible products | devolo Magic |
| Power |
|---|
| Power over Ethernet (PoE) | No |
| Power consumption (typical) | 5.1 W |
| Power consumption (standby) | 2 W |
| AC input voltage | 196 - 250 V |
| AC input frequency | 50 Hz |
| Current | 16 A |
| Design |
|---|
| Antenna type | Internal |
| LED indicators | Yes |
| Product colour | White |
| Certification | CE |
| Antennas quantity | 4 |
| System requirements |
|---|
| Mac compatibility | Yes |
| Windows operating systems supported | Yes |
| Linux operating systems supported | Yes |
| Mac operating systems supported | Mac OS X 10.10 Yosemite, Mac OS X 10.11 El Capitan, Mac OS X 10.12 Sierra, Mac OS X 10.13 High Sierra, Mac OS X 10.14 Mojave, Mac OS X 10.9 Mavericks |
| Mobile operating systems supported | Android 5.1, Android 6.0, Android 7.1, Android 7.1.2, iOS 10.0, iOS 11.0 |
| Operational conditions |
|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -25 - 70 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Weight & dimensions |
|---|
| Width | 76 mm |
| Depth | 40 mm |
| Height | 152 mm |
| Package width | 190 mm |
| Package depth | 118 mm |
| Package height | 92 mm |
| Package weight | 570 g |
| Packaging content |
|---|
| Quantity per pack | 1 pc(s) |
| Quick installation guide | Yes |
| Cables included | LAN (RJ-45) |
