| Data transmission |
|---|
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Maximum data transfer rate | 1200 Mbit/s |
| Performance |
|---|
| Operating modes | Access Point (AP),Gateway,Repeater,WISP |
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Wi-Fi Multimedia (WMM)/(WME) | Yes |
| Flow control support | Yes |
| Country of origin | China |
| Reset button | Yes |
| Firmware upgradeable | Yes |
| Frequency band | 2.4 - 2.4835, 5.15 - 5.35, 5.46 - 5.72, 5.725 - 5.825 GHz |
| Number of users | 100 user(s) |
| Web-based management | Yes |
| Quality of Service (QoS) support | Yes |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x |
| Modulation | 16-QAM, 64-QAM, BPSK, CCK, DBPSK, DQPSK, DSSS, OFDM, QPSK |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Channels quantity | 165 channels |
| Certification | CE |
| Maximum data transfer rate | 1200 Mbit/s |
| Wireless LAN features |
|---|
| Frequency band | 2.4 - 2.4835, 5.15 - 5.35, 5.46 - 5.72, 5.725 - 5.825 GHz |
| Modulation | 16-QAM, 64-QAM, BPSK, CCK, DBPSK, DQPSK, DSSS, OFDM, QPSK |
| Channels quantity | 165 channels |
| Network |
|---|
| Internal | No |
| Number of users | 100 user(s) |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x |
| Management features |
|---|
| Quality of Service (QoS) support | Yes |
| Firmware upgradeable | Yes |
| Web-based management | Yes |
| Certificates |
|---|
| Certification | CE |
| Features |
|---|
| Operating modes | Access Point (AP),Gateway,Repeater,WISP |
| 2.4 GHz | Yes |
| 5 GHz | Yes |
| Wi-Fi Multimedia (WMM)/(WME) | Yes |
| Flow control support | Yes |
| Frequency band | 2.4 - 2.4835, 5.15 - 5.35, 5.46 - 5.72, 5.725 - 5.825 GHz |
| Number of users | 100 user(s) |
| Quality of Service (QoS) support | Yes |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11e, IEEE 802.11g, IEEE 802.11i, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x |
| Modulation | 16-QAM, 64-QAM, BPSK, CCK, DBPSK, DQPSK, DSSS, OFDM, QPSK |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Channels quantity | 165 channels |
| Maximum data transfer rate | 1200 Mbit/s |
| Maximum data transfer rate (5 GHz) | 867 Mbit/s |
| Security |
|---|
| Number of SSID supported | 4 |
| Security algorithms | 64-bit WEP, 128-bit WEP, WPA, WPA-PSK, WPA2, WPA2-PSK |
| Service Set Identifier (SSID) features | SSID broadcast on/off |
| Ports & interfaces |
|---|
| WAN connection | Ethernet (RJ-45) |
| USB 2.0 ports quantity | 2 |
| Ethernet LAN (RJ-45) ports | 5 |
| Power |
|---|
| Power consumption (typical) | 17 W |
| Input current | 1.5 A |
| AC input voltage | 12 V |
| Design |
|---|
| Placement | Table |
| Country of origin | China |
| Product colour | Silver |
| Reset button | Yes |
| Internal | No |
| Certification | CE |
| Antenna |
|---|
| Antennas quantity | 6 |
| Antenna gain level (max) | 6 dBi |
| Technical details |
|---|
| Reset button | Yes |
| Firmware upgradeable | Yes |
| Harmonized System (HS) code | 85176990 |
| Weight & dimensions |
|---|
| Width | 128 mm |
| Depth | 198 mm |
| Weight | 660 g |
| Height | 28 mm |
| Package width | 220 mm |
| Package depth | 285 mm |
| Package height | 65 mm |
| Package weight | 1.32 kg |
| Packaging data |
|---|
| Quick start guide | Yes |
| Package type | Box |
| CD manual | Yes |
| Package width | 220 mm |
| Package depth | 285 mm |
| Package height | 65 mm |
| Package weight | 1.32 kg |
| Cables included | LAN (RJ-45) |
| AC adapter included | Yes |
| Packaging content |
|---|
| Quick start guide | Yes |
| Cables included | LAN (RJ-45) |
| AC adapter included | Yes |
| Package type | Box |
| CD manual | Yes |
| Operational conditions |
|---|
| Operating relative humidity (H-H) | 10 - 90% |
| Operating temperature (T-T) | 0 - 40 °C |
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 5 - 90% |
| Logistics data |
|---|
| Master (outer) case width | 300 mm |
| Master (outer) case length | 685 mm |
| Master (outer) case height | 245 mm |
| Master (outer) case gross weight | 14 kg |
| Products per master (outer) case | 10 pc(s) |
| Harmonized System (HS) code | 85176990 |
