| Management features |
|---|
| Multicast support | Yes |
| Switch type | Managed |
| Web-based management | Yes |
| Quality of Service (QoS) support | Yes |
| Switch layer | L2+ |
| Ports & interfaces |
|---|
| Copper ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
| SFP module slots quantity | 2 |
| Basic switching RJ-45 Ethernet ports quantity | 16 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Gigabit Ethernet (copper) ports quantity | 16 |
| Network |
|---|
| IGMP snooping | Yes |
| Cable types supported | Cat3, Cat4, Cat5, Cat5e |
| Auto-sensing | Yes |
| Copper ethernet cabling technology | 10BASE-T, 100BASE-TX, 1000BASE-T |
| Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3az, IEEE 802.3u |
| Full duplex | Yes |
| VLAN support | Yes |
| Spanning tree protocol | No |
| Rate limiting | Yes |
| Port mirroring | Yes |
| Number of VLANs | 4096 |
| Link aggregation | Yes |
| Flow control support | Yes |
| Broadcast storm control | Yes |
| Auto MDI/MDI-X | Yes |
| 10G support | No |
| Virtual LAN features | Tagged VLAN, Port-based VLAN |
| Virtual LAN features |
|---|
| VLAN support | Yes |
| Number of VLANs | 4096 |
| Virtual LAN features | Tagged VLAN, Port-based VLAN |
| Data transmission |
|---|
| Number of VLANs | 4096 |
| Packet forwarding rate (100 Mbps) | 148800 pps |
| Packet forwarding rate (10 Mbps) | 14880 pps |
| Packet forwarding rate (1 Gbps) | 1488000 pps |
| Jumbo frames | 9000 |
| Packet buffer memory | 0.512 MB |
| MAC address table | 8000 entries |
| Switching capacity | 36 Gbit/s |
| Store-and-forward | Yes |
| Jumbo frames support | Yes |
| Performance |
|---|
| Packet buffer memory | 0.512 MB |
| Harmonized System (HS) code | 85176990 |
| Technical details |
|---|
| Form factor | 1U |
| Product colour | Black |
| Housing material | Metal |
| Rack mounting | Yes |
| Power over Ethernet (PoE) |
|---|
| Power protection features | Over voltage, Overload, Short circuit |
| Power over Ethernet (PoE) power per port | 30 W |
| Power over Ethernet plus (PoE+) ports quantity | 16 |
| Total Power over Ethernet (PoE) budget | 220 W |
| Power over Ethernet (PoE) | Yes |
| Security |
|---|
| Authentication | Port-based authentication |
| Security algorithms | 802.1x RADIUS, HTTPS, SSH, SSH-2 |
| IGMP snooping | Yes |
| Access Control List (ACL) | Yes |
| Multicast features |
|---|
| Multicast support | Yes |
| Protocols |
|---|
| Management protocols | SNMP, Telnet, SSH |
| Certificates |
|---|
| Certification | FCC Class A, CE |
| Memory |
|---|
| Packet buffer memory | 0.512 MB |
| Design |
|---|
| Form factor | 1U |
| Product colour | Black |
| LED indicators | Yes |
| Housing material | Metal |
| Certification | FCC Class A, CE |
| Rack mounting | Yes |
| Number of fans | 2 fan(s) |
| Indication |
|---|
| LED indicators | Yes |
| Power |
|---|
| Power consumption (max) | 260 W |
| Power protection features | Over voltage, Overload, Short circuit |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power source | AC |
| Operational conditions |
|---|
| Storage temperature (T-T) | -20 - 90 °C |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Weight & dimensions |
|---|
| Width | 440 mm |
| Depth | 208 mm |
| Height | 44 mm |
| Weight | 3.86 kg |
| Packaging data |
|---|
| Rack mount kit | Yes |
| Manual | Yes |
| Cables included | AC |
| Logistics data |
|---|
| Harmonized System (HS) code | 85176990 |
| Packaging content |
|---|
| Rack mount kit | Yes |
| Manual | Yes |
| Cables included | AC |
