| Management features |
|---|
| Traffic classification | Yes |
| ARP inspection | Yes |
| Switch type | Managed |
| Web-based management | Yes |
| System event log | Yes |
| Quality of Service (QoS) support | Yes |
| Multicast support | Yes |
| MIB support | RFC2925, RFC2618, RFC2620, RFC2021, RFC2819, RFC2674, RFC1493, RFC1643, RFC2233, RFC1213 |
| Switch layer | L2+/L3 |
| Configuring Location Settings (CLI) | Yes |
| Cloud-managed | Yes |
| Ports & interfaces |
|---|
| SFP+ module slots quantity | 16 |
| Basic switching RJ-45 Ethernet ports quantity | 0 |
| Basic switching RJ-45 Ethernet ports type | No |
| Installed SFP modules quantity | 0 |
| Installed SFP+ modules quantity | 0 |
| Console port | RJ-45/Micro-USB |
| Power connector | DC-in jack |
| Network |
|---|
| Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3ad, IEEE 802.3x |
| Head-of-line (HOL) blocking | Yes |
| VLAN support | Yes |
| Spanning tree protocol | Yes |
| Rate limiting | Yes |
| Port mirroring | Yes |
| Number of VLANs | 4000 |
| Link aggregation | Yes |
| IP routing | Yes |
| Flow control support | Yes |
| Broadcast storm control | Yes |
| 10G support | Yes |
| Virtual LAN features | Private VLAN, Protocol-based VLAN, Tagged VLAN, Voice VLAN |
| IGMP snooping | Yes |
| Data transmission |
|---|
| Jumbo frames | 9000 |
| Packet buffer memory | 24 MB |
| MAC address table | 32000 entries |
| Switching capacity | 320 Gbit/s |
| Number of queues | 8 |
| Jumbo frames support | Yes |
| Static route | Yes |
| Forwarding rate | 238.08 Mpps |
| Number of VLANs | 4000 |
| Multicast Listener Discovery (MLD) snooping | Yes |
| Security |
|---|
| Loop protection | Yes |
| IP-MAC-Port binding | Yes |
| BPDU filtering/protection | Yes |
| Authentication | Guest VLAN, MAC-based authentication, Port-based authentication, Web-based authentication |
| Static port security | Yes |
| SSH/SSL support | Yes |
| Security algorithms | HTTPS, SSH, SSH-2, SSL/TLS |
| MAC address filtering | Yes |
| IGMP snooping | Yes |
| Access Control List (ACL) | Yes |
| Queue scheduling algorithms | SP, WRR+SP, Weighted Round Robin (WRR) |
| Authentication type | AAA, TACACS+ |
| DHCP features | DHCP relay, DHCP server, DHCP snooping, DHCPv6 client, DHCPv6 snooping |
| Multicast features |
|---|
| Multicast support | Yes |
| Multicast Listener Discovery (MLD) snooping | Yes |
| Protocols |
|---|
| Management protocols | SNMPv1/v2c/v3, SNTP |
| IPv4 & IPv6 features | IPv6 Telnet, IPv6 ping, IPv6 tracert |
| Design |
|---|
| Product colour | Black |
| LED indicators | Yes |
| Rack mounting | Yes |
| Certification | CE, FCC, RoHS |
| Power |
|---|
| Power consumption (max) | 32.74 W |
| Power supply included | Yes |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Power source | AC |
| Power connector | DC-in jack |
| Power over Ethernet (PoE) |
|---|
| Power over Ethernet (PoE) | No |
| Operational conditions |
|---|
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 5 - 90% |
| Operating temperature (T-T) | 0 - 45 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Heat dissipation | 111.71 BTU/h |
| Virtual LAN features |
|---|
| VLAN support | Yes |
| Number of VLANs | 4000 |
| Virtual LAN features | Private VLAN, Protocol-based VLAN, Tagged VLAN, Voice VLAN |
| Weight & dimensions |
|---|
| Width | 440 mm |
| Depth | 220 mm |
| Height | 44 mm |
| Packaging content |
|---|
| Rack mount kit | Yes |
| Quick start guide | Yes |
| Manual | Yes |
| Cables included | AC |
| Packaging data |
|---|
| Package type | Box |
| Package width | 528 mm |
| Package depth | 336 mm |
| Package height | 100 mm |
| Package weight | 3.7 kg |
| Rack mount kit | Yes |
| Quick start guide | Yes |
| Manual | Yes |
| Cables included | AC |
| IPv4 & IPv6 features |
|---|
| IPv4 & IPv6 features | IPv6 Telnet, IPv6 ping, IPv6 tracert |
| Performance |
|---|
| Packet buffer memory | 24 MB |
| Harmonized System (HS) code | 85176990 |
| Technical details |
|---|
| Product colour | Black |
| Rack mounting | Yes |
| Memory |
|---|
| Packet buffer memory | 24 MB |
| Certificates |
|---|
| Certification | CE, FCC, RoHS |
| Indication |
|---|
| LED indicators | Yes |
| Logistics data |
|---|
| Harmonized System (HS) code | 85176990 |
