| Management features |
|---|
| Multicast support | Yes |
| ARP inspection | Yes |
| Switch type | Managed |
| Web-based management | Yes |
| System event log | Yes |
| Quality of Service (QoS) support | Yes |
| MIB support | Yes |
| Switch layer | L2+ |
| Configuring Location Settings (CLI) | Yes |
| Cloud-managed | Yes |
| Network |
|---|
| IGMP snooping | Yes |
| Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3x |
| Head-of-line (HOL) blocking | Yes |
| VLAN support | Yes |
| Spanning tree protocol | Yes |
| Routing entries | 512 |
| Rate limiting | Yes |
| Port mirroring | Yes |
| Number of VLANs | 4000 |
| Link aggregation | Yes |
| IP routing | Yes |
| Flow control support | Yes |
| Broadcast storm control | Yes |
| 10G support | Yes |
| Virtual LAN features | Private VLAN, Tagged VLAN, VLAN mapping, Voice VLAN |
| Virtual LAN features |
|---|
| VLAN support | Yes |
| Number of VLANs | 4000 |
| Virtual LAN features | Private VLAN, Tagged VLAN, VLAN mapping, Voice VLAN |
| Data transmission |
|---|
| Number of VLANs | 4000 |
| Multicast Listener Discovery (MLD) snooping | MLD v1/v2 |
| Jumbo frames | 9000 |
| Number of static routes | 48 |
| MAC address table | 32000 entries |
| Switching capacity | 120 Gbit/s |
| Jumbo frames support | Yes |
| Static route | Yes |
| Forwarding rate | 89.28 Mpps |
| Power |
|---|
| Power connector | AC-in jack |
| Power consumption (max) | 244.9 W |
| Power supply included | Yes |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Power source | AC |
| Technical details |
|---|
| Product colour | Black |
| Rack mounting | Yes |
| Ports & interfaces |
|---|
| SFP+ module slots quantity | 2 |
| Basic switching RJ-45 Ethernet ports quantity | 4 |
| Basic switching RJ-45 Ethernet ports type | 10G Ethernet (100/1000/10000) |
| Console port | RJ-45/Micro-USB |
| Power connector | AC-in jack |
| Security |
|---|
| Loop protection | Yes |
| BPDU filtering/protection | Yes |
| Authentication | Guest VLAN |
| SSH/SSL support | Yes |
| Security algorithms | HTTPS, SSL/TLS |
| IGMP snooping | Yes |
| Access Control List (ACL) | Yes |
| Authentication type | AAA, RADIUS, TACACS+ |
| DHCP features | DHCP client, DHCP relay, DHCP server, DHCP snooping, DHCPv6 client |
| Multicast features |
|---|
| Multicast support | Yes |
| Multicast Listener Discovery (MLD) snooping | MLD v1/v2 |
| Protocols |
|---|
| Management protocols | SNMP v1/v2c/v3 |
| Certificates |
|---|
| Certification | CE, FCC, RoHS |
| Design |
|---|
| Product colour | Black |
| LED indicators | Yes |
| Certification | CE, FCC, RoHS |
| Rack mounting | Yes |
| Number of fans | 2 fan(s) |
| Performance |
|---|
| Minimum system requirements | Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ / Windows 7/8/10/11, MAC® OS, NetWare®, UNIX® /Linux. |
| Harmonized System (HS) code | 85176990 |
| Indication |
|---|
| LED indicators | Yes |
| System requirements |
|---|
| Minimum system requirements | Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ / Windows 7/8/10/11, MAC® OS, NetWare®, UNIX® /Linux. |
| Power over Ethernet (PoE) |
|---|
| Power over Ethernet (PoE) power per port | 60 W |
| Power over Ethernet plus (PoE+) ports quantity | 4 |
| Total Power over Ethernet (PoE) budget | 200 W |
| Power over Ethernet (PoE) | Yes |
| Operational conditions |
|---|
| Storage temperature (T-T) | -40 - 70 °C |
| Storage relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | 0 - 50 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Heat dissipation | 835.67 BTU/h |
| Weight & dimensions |
|---|
| Width | 294 mm |
| Depth | 180 mm |
| Height | 44 mm |
| Packaging data |
|---|
| Rack mount kit | Yes |
| Quick start guide | Yes |
| Package width | 400 mm |
| Package depth | 250 mm |
| Package height | 80 mm |
| Package weight | 2.62 kg |
| Cables included | AC |
| Logistics data |
|---|
| Harmonized System (HS) code | 85176990 |
| Packaging content |
|---|
| Rack mount kit | Yes |
| Quick start guide | Yes |
| Cables included | AC |
