| Management features |
|---|
| ARP inspection | Yes |
| Switch type | Managed |
| Web-based management | Yes |
| Quality of Service (QoS) support | Yes |
| Multicast support | Yes |
| Switch layer | L3 |
| Ports & interfaces |
|---|
| SFP+ module slots quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | No |
| USB 2.0 ports quantity | 2 |
| Console port | RJ-45 |
| Power connector | AC-in jack |
| SFP28 ports quantity | 4 |
| Network |
|---|
| Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1Qav, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ak, IEEE 802.3bz, IEEE 802.3u |
| Full duplex | Yes |
| VLAN support | Yes |
| Spanning tree protocol | Yes |
| Rate limiting | Yes |
| Number of VLANs | 4093 |
| Link aggregation | Yes |
| Flow control support | Yes |
| Broadcast storm control | Yes |
| 10G support | Yes |
| Policy-based routing | Yes |
| 6to4 tunnel | Yes |
| Virtual LAN features | MAC address-based VLAN, Private VLAN, Voice VLAN |
| IPv6 routes | 256 |
| IPv4 routes | 512 |
| IGMP snooping | Yes |
| GARP VLAN Registration Protocol (GVRP) | Yes |
| IGMP proxy | Yes |
| Data transmission |
|---|
| Jumbo frames | 12000 |
| Throughput | 505.92 Mpps |
| Latency (1 Gbps) | 1.06 µs |
| Latency (10 Gbps) | 0.63 µs |
| Packet buffer memory | 32 MB |
| MAC address table | 16000 entries |
| Switching capacity | 680 Gbit/s |
| Store-and-forward | Yes |
| Jumbo frames support | Yes |
| Static route | Yes |
| Number of VLANs | 4093 |
| Multicast Listener Discovery (MLD) snooping | Yes |
| Security |
|---|
| Loop protection | Yes |
| BPDU filtering/protection | Yes |
| Authentication | Guest VLAN, MAC-based authentication |
| Static port security | Yes |
| MAC address filtering | Yes |
| IGMP snooping | Yes |
| Access Control List (ACL) | Yes |
| Root protection | Yes |
| Queue scheduling algorithms | Strict Priority Queue (SPQ), Weighted random early detection (WRED) |
| Password protection | Yes |
| DoS attack prevention | Yes |
| Authentication type | RADIUS, TACACS+ |
| Access Control List (ACL) ingress | 511 |
| Access Control List (ACL) egress | 1023 |
| IGMP proxy | Yes |
| DHCP features | DHCP Option 150, DHCP Option 66, DHCP Option 67, DHCP relay, DHCP server, DHCP snooping |
| Multicast features |
|---|
| Multicast support | Yes |
| Multicast Listener Discovery (MLD) snooping | Yes |
| Protocols |
|---|
| Management protocols | SNMP V1, V2, V3 |
| GARP VLAN Registration Protocol (GVRP) | Yes |
| Routing protocols | OSPF, OSPFv2, OSPFv3, RIP, RIP-1, RIP-2 |
| Design |
|---|
| Form factor | 1U |
| Product colour | Black |
| Stackable | Yes |
| LED indicators | Yes |
| Rack mounting | Yes |
| Airflow direction | Front-to-back airflow |
| Performance |
|---|
| Processor frequency | 1800 MHz |
| Noise level | 61.8 dB |
| Memory type | DDR4-SDRAM |
| Mean time between failures (MTBF) | 778741 h |
| Internal memory | 2048 MB |
| Flash memory | 512 MB |
| sFlow | Yes |
| Built-in processor | Yes |
| Processor model | ARM Cortex-A57 |
| Packet buffer memory | 32 MB |
| Stackable | Yes |
| Power |
|---|
| Power supply included | Yes |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50/60 Hz |
| Power consumption (typical) | 119.3 W |
| Input current | 6.3 A |
| Power source | AC |
| Power connector | AC-in jack |
| Power over Ethernet (PoE) |
|---|
| Power over Ethernet (PoE) | No |
| Other features |
|---|
| Power supply | 240 W |
| Operational conditions |
|---|
| Storage temperature (T-T) | -20 - 70 °C |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating temperature (T-T) | 0 - 50 °C |
| Operating relative humidity (H-H) | 0 - 90% |
| Operating altitude | 0 - 3000 m |
| Non-operating altitude | 0 - 3000 m |
| Heat dissipation | 374.6 BTU/h |
| Virtual LAN features |
|---|
| VLAN support | Yes |
| Number of VLANs | 4093 |
| Virtual LAN features | MAC address-based VLAN, Private VLAN, Voice VLAN |
| Weight & dimensions |
|---|
| Width | 440 mm |
| Depth | 400 mm |
| Height | 43.2 mm |
| Weight | 6.25 kg |
| Packaging content |
|---|
| Rack mount kit | Yes |
| User guide | Yes |
| Cables included | AC, USB Type-C |
| Included power plug types | EU, NA, UK |
| Packaging data |
|---|
| Included power plug types | EU, NA, UK |
| Rack mount kit | Yes |
| User guide | Yes |
| Cables included | AC, USB Type-C |
| Sustainability |
|---|
| Sustainability compliance | Yes |
| Technical details |
|---|
| Form factor | 1U |
| Product colour | Black |
| Stackable | Yes |
| Processor frequency | 1800 MHz |
| Noise level | 61.8 dB |
| Mean time between failures (MTBF) | 778741 h |
| Rack mounting | Yes |
| Built-in processor | Yes |
| Sustainability compliance | Yes |
| Compliance certificates | BSMI, CCC, CE, Federal Communications Commission (FCC), Low Voltage Directive (LVD) |
| Memory |
|---|
| Packet buffer memory | 32 MB |
| Memory type | DDR4-SDRAM |
| Internal memory | 2048 MB |
| Flash memory | 512 MB |
| Certificates |
|---|
| Compliance certificates | BSMI, CCC, CE, Federal Communications Commission (FCC), Low Voltage Directive (LVD) |
| Indication |
|---|
| LED indicators | Yes |
| Mobile network |
|---|
| GARP VLAN Registration Protocol (GVRP) | Yes |
