| Management features |
|---|
| Switch type | Managed |
| Web-based management | Yes |
| Quality of Service (QoS) support | Yes |
| Multicast support | Yes |
| Switch layer | L3 |
| Configuring Location Settings (CLI) | Yes |
| Ports & interfaces |
|---|
| SFP+ module slots quantity | 2 |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Installed SFP modules quantity | 0 |
| Installed SFP+ modules quantity | 0 |
| Gigabit Ethernet (copper) ports quantity | 24 |
| Fiber optic connector | SFP+ |
| Console port | RJ-45 |
| Power connector | AC-in jack |
| Network |
|---|
| Networking standards | IEEE 802.1D, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ad, IEEE 802.1ak, IEEE 802.1p, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3az, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| VLAN support | Yes |
| Spanning tree protocol | Yes |
| Port mirroring | Yes |
| Number of VLANs | 4096 |
| Link aggregation | Yes |
| Flow control support | Yes |
| Broadcast storm control | Yes |
| 10G support | Yes |
| Virtual LAN features | IP subnet–based VLAN, MAC address-based VLAN, MVRP, Port-based VLAN, Private VLAN, Tagged VLAN, VLAN Identifier ( VLAN ID), Voice VLAN |
| IGMP snooping | Yes |
| GARP VLAN Registration Protocol (GVRP) | Yes |
| IGMP proxy | Yes |
| Data transmission |
|---|
| Jumbo frames | 10240 |
| Throughput | 130 Mpps |
| Number of static routes | 128 |
| MAC address table | 32000 entries |
| Switching capacity | 88 Gbit/s |
| Store-and-forward | Yes |
| Jumbo frames support | Yes |
| Static route | Yes |
| Number of VLANs | 4096 |
| Multicast Listener Discovery (MLD) snooping | Yes |
| Security |
|---|
| Loop protection | Yes |
| Authentication | Guest VLAN |
| SSH/SSL support | Yes |
| Security algorithms | SNMPv3 |
| MAC address filtering | Yes |
| IGMP snooping | Yes |
| Access Control List (ACL) | Yes |
| Authentication type | IEEE 802.1x, RADIUS, TACACS+ |
| IGMP proxy | Yes |
| DHCP features | DHCP Option 66, DHCP Option 67, DHCP Option 82, DHCP client, DHCP relay, DHCP server, DHCP snooping |
| Multicast features |
|---|
| Multicast support | Yes |
| Multicast Listener Discovery (MLD) snooping | Yes |
| Protocols |
|---|
| GARP VLAN Registration Protocol (GVRP) | Yes |
| IP Source Guard (IPSG) | Yes |
| Design |
|---|
| Form factor | 1U |
| Product colour | Black |
| LED indicators | Activity, Link, Speed, System |
| Housing material | Metal |
| Rack mounting | Yes |
| Number of fans | 1 fan(s) |
| Country of origin | Taiwan |
| Performance |
|---|
| Noise level | 34 dB |
| Firmware upgradeable | Yes |
| Harmonized System (HS) code | 85176990 |
| Power |
|---|
| Power consumption (max) | 30 W |
| Power supply included | Yes |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power source | AC |
| Power connector | AC-in jack |
| Power over Ethernet (PoE) |
|---|
| Power over Ethernet (PoE) | No |
| Operational conditions |
|---|
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 10 - 90% |
| Heat dissipation | 102 BTU/h |
| Virtual LAN features |
|---|
| VLAN support | Yes |
| Number of VLANs | 4096 |
| Virtual LAN features | IP subnet–based VLAN, MAC address-based VLAN, MVRP, Port-based VLAN, Private VLAN, Tagged VLAN, VLAN Identifier ( VLAN ID), Voice VLAN |
| Weight & dimensions |
|---|
| Width | 442 mm |
| Depth | 211 mm |
| Height | 44 mm |
| Weight | 2.7 kg |
| Packaging content |
|---|
| Quick start guide | Yes |
| Cables included | AC, Serial |
| Mounting brackets included | Yes |
| Packaging data |
|---|
| Mounting brackets included | Yes |
| Package width | 470 mm |
| Package depth | 540 mm |
| Package height | 985 mm |
| Package weight | 3.6 kg |
| Quick start guide | Yes |
| Cables included | AC, Serial |
| Optical fiber |
|---|
| Fiber optic connector | SFP+ |
| Technical details |
|---|
| Form factor | 1U |
| Product colour | Black |
| Noise level | 34 dB |
| Housing material | Metal |
| Firmware upgradeable | Yes |
| Rack mounting | Yes |
| Compliance certificates | CE, Federal Communications Commission (FCC) |
| Certificates |
|---|
| Compliance certificates | CE, Federal Communications Commission (FCC) |
| Indication |
|---|
| LED indicators | Activity, Link, Speed, System |
| Mobile network |
|---|
| GARP VLAN Registration Protocol (GVRP) | Yes |
| Other features |
|---|
| Country of origin | Taiwan |
| Logistics data |
|---|
| Country of origin | Taiwan |
| Harmonized System (HS) code | 85176990 |
| Customs product code (TARIC) | 85176200 |
