| Ports & interfaces |
|---|
| Combo headphone/mic port | Yes |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 0 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 1 |
| Headphone connectivity | 3.5 mm |
| Host interface | USB 3.2 Gen 2 (3.1 Gen 2) Type-C |
| USB 2.0 ports quantity | 0 |
| HDMI ports quantity | 1 |
| HDMI version | 1.4 |
| Headphone outputs | 1 |
| Connectivity technology | Wired |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery up to | 100 W |
| DisplayPort version | 1.2 |
| HDCP version | 1.4 |
| HDCP | Yes |
| USB Type-C DisplayPort Alternate Mode | Yes |
| Network |
|---|
| Ethernet LAN | No |
| Performance |
|---|
| Maximum digital resolution | 3840 x 2160 pixels |
| Product colour | Grey |
| Card reader integrated | No |
| Data transfer rate | 10 Gbit/s |
| HD type | 4K Ultra HD |
| Housing material | Aluminium |
| Technical details |
|---|
| Product colour | Grey |
| Data transfer rate | 10 Gbit/s |
| Compliance certificates | UKCA, REACH, Federal Communications Commission (FCC), RoHS, CE |
| User guide | Yes |
| Products per master (outer) case | 100 pc(s) |
| Master (outer) case width | 300 mm |
| Master (outer) case gross weight | 4.5 kg |
| Master (outer) case length | 540 mm |
| Master (outer) case height | 185 mm |
| Storage |
|---|
| Card reader integrated | No |
| Power |
|---|
| Power source type | USB |
| Software |
|---|
| Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 Enterprise, Windows 11 Enterprise x64, Windows 11 Home, Windows 11 Pro, Windows 11 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64 |
| Mac operating systems supported | Yes |
| Other operating systems supported | ChromeOS |
| Mobile operating systems supported | Android, iOS, iPadOS |
| Operational conditions |
|---|
| Operating temperature (T-T) | 0 - 50 °C |
| Operating relative humidity (H-H) | 0 - 85% |
| Weight & dimensions |
|---|
| Weight | 21 g |
| Width | 28 mm |
| Depth | 77 mm |
| Height | 10 mm |
| Package weight | 30 g |
| Package width | 80 mm |
| Package depth | 120 mm |
| Package height | 20 mm |
| Design |
|---|
| Windows operating systems supported | Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 Enterprise, Windows 11 Enterprise x64, Windows 11 Home, Windows 11 Pro, Windows 11 x64, Windows 7, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 7 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64 |
| Mac operating systems supported | Yes |
| Product colour | Grey |
| Packaging data |
|---|
| Package weight | 30 g |
| Package width | 80 mm |
| Package depth | 120 mm |
| Package height | 20 mm |
| Packaging content |
|---|
| User guide | Yes |
| Logistics data |
|---|
| Products per master (outer) case | 100 pc(s) |
| Master (outer) case width | 300 mm |
| Master (outer) case gross weight | 4.5 kg |
| Master (outer) case length | 540 mm |
| Master (outer) case height | 185 mm |
